AXABH-CH4

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 2/23/23 INSTAXABH-CH4

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip ties

TABLE OF CONTENTS

Amplifier locations ................................................2

Connections

22-Pin Harness ................................................3-6

10-Pin Harness .................................................7-8

Chrysler Amplifier Bypass Harness 2015-Up

Refer to the following pages for the vehicle specific instructions

for wiring connections. Wiring connections vary per vehicle. Please

note that there are (2) different wiring harnesses included, and the

instructions for each harness will be on a different page. *

If it’s uncertain whether the vehicle contains a specific speaker or not,

test the wires with a tone generator, or check to see if the factory

wires are populated on the vehicle side. Alternatively, the wires can

be tested for impedance with a multimeter.

APPLICATIONS

Alfa Romeo

Giulia 2017-2018

Stelvio 2018

Chrysler

300* 2016-Up

Pacifica 2017-2018

Dodge

Challenger*** 2016-Up

Charger* 2016-Up

Durango SRT 2018-Up

Viper 2016-2018

Jeep

Cherokee

†

2019-Up

Gladiator 2020-Up

Grand Cherokee* 2015-Up

Wrangler (JL body type) 2018-Up

Ram

Ram 1500 (exclude Classic)* 2019

Ram 1500 (exclude Classic)** 2019

* With Premium amp

** With Premium Plus amp

*** With Mid-line amp

†

With Active Noise Control (ANC)

* Excluding Jeep Wrangler

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date

vehicle specific applications

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the

ignition to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.
