AX-DSPHNS

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 11/2/18 INSTAX-DPSHNS

Attention!Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

TABLE OF CONTENTS

20-Pin Harness Pinout...........................................2

Additional Wiring & Notes ....................................3

AX-DSP T-Harness

The Axxess T-harness is a basic and simple plug-n-play harness for easy installation of the AX-DSP (sold separately) for vehicle

specific applications. Most T-harnesses created by Axxess will either have a 4-pin or 8-pin harness, with the speaker wires pinned.

If you are installing a 4-channel amplifier with the AX-DSP, leave these connectors disconnected. The only reason for connecting

these harnesses together would be if the AX-DSP is being used for adding a subwoofer amplifier only. Some T-harnesses require

additional wiring and/or installation steps. Refer to the following page for a pinout legend for the 20-pin harness, and also

additional wiring and notes.
