AXAC-MZ2
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 1/31/23 INSTAXAC-MZ2
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product.
Ensure that all installation connections,
especially the air bag indicator lights, are
plugged in before reconnecting the battery
or cycling the ignition to test this product.
NOTE: Refer also to the instructions
included with the aftermarket accessory
before installing this device.
INTERFACE FEATURES
TOOLS REQUIRED
INTERFACE COMPONENTS
REQUIRED ITEMS
TABLE OF CONTENTS
Introduction............................................................2
Configuration .....................................................2-4
Connections ............................................................5
Installation .............................................................6
Programming .........................................................6
(4) Camera inputs
Reverse signal trigger generated via CAN bus communication of the vehicle
Turn signal trigger generated via CAN bus communication of the vehicle
(4) Programmable camera control wires
Micro-B USB updatable
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip-ties
• AXAC-MZ2 interface
• AXAC-MZ2 interface harness
• AXAC-MZ2 vehicle harness (qty. 2)
• 18-pin T-harness
• 28-pin T-harness (cam harness)
Update Cable: AXUSB-MCBL (sold separately)
Axxess Updater Program
With full color LCD screen
Mazda† Camera Interface with Pre-Wired Harness
2014-Up
APPLICATIONS
Mazda
CX-3 2016-Up
CX-9 2016-Up
Mazda 3 2014-Up
Note: Only compatible with NTSC cameras.
Visit AxxessInterfaces.com for more detailed information
about the product and up-to-date vehicle specific applications
