© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

axxessinterfaces.com • metraonline.com

Axxess Integrate

REV. 1/28/20

Installation Instructions for AXBUCH-T36V

INTERFACE FEATURES

• Retains the factory backup camera to an aftermarket radio

• Allows an aftermarket camera to be added to the factory screen*

• Includes the AXCSD-6V 12-volt to 6-volt converter

* Display and navigation model radios only

INTERFACE COMPONENTS

• AXBUCH-T36V harness • AXCSD-6V 12-volt to 6-volt converter

AXBUCH-T36V

Toyota Backup Camera Retain/Add-On

2013-2016

SCION

FR-S 2016

iM 2016

tC 2016

TOYOTA

4-Runner 2014-2016

4-Runner (without NAV) 2013

Avalon 2015-2016

Camry 2014-2016

Corolla 2014-2016

Highlander 2014-2016

Prius C 2015

Prius V 2015

Rav-4 2015-2016

Rav-4 (after build

date Nov. 2013)2014

Sienna 2015

Sequoia 2014-2016

Tacoma 2014-2016

Tundra 2014-2016

Venza 2015-2016

• Cutting tool • Tape • Crimping tool

• Connectors (example: butt connectors, bell caps, etc.)

APPLICATIONS

TOOLS REQUIRED

CAUTION!

All accessories, switches, climate controls panels, and especially air bag indicator lights

must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.
