AXDI-CL2

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20 INSTAXDI-CL2

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections .........................................................2-3

Installation .............................................................3

Programming .........................................................3

GM Data Interface 2000-2013

APPLICATIONS

See inside front cover

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

•

Provides illumination, parking brake, reverse, and speed sense outputs

• Retains chimes through an onboard speaker

• Pre-wired AXSWC harness (AXSWC sold separately)

• Designed for non-amplified models, analog amplified models,

or when bypassing a factory amplifier

• Retains balance and fade

• Micro-B USB updatable

• AXDI-CL2 interface

• AXDI-CL2 harness
