AXDSPL-BT

INSTALLATION INSTRUCTIONS

REV. 5/1/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.com

16-pin Header

AX-DSPL-BT

AX-DSPL-BT

The AXDSPL-BT will be used for adding a Bluetooth interface to the

AXDSP-L for playing music files directly to the interface.

•

While playing music the volume on the phone will be used. As an

option, the AXBK-1 (sold separately) can be used to control the volume

.

The Note: AXBK-1AXDSP-L included with the can also be used if it

will not be used to control a subwoofer.

1.Unplug the Important!AXDSP-L from the vehicle.

2.Remove (4) Phillips screws securing the AXDSP-L interface, then

remove the top cover, exposing the circuit board within.

3.Locate the 16-pin header on the circuit board.

4. Referencing how the Bluetooth interface is laid out Important!

in the picture, carefully line up the header pins to the AXDSPL-BT

Bluetooth interface. Gently press down to secure.

Both interfaces may be damaged if installed wrong.Note:

5.Reinstall the top cover to complete the installation.

AXBK-1 installation:

6.BrownConnect the wire from the AXDSP-L to the wire Orange

from the AXBK-1. Ground the wire from the AXBK-1.Black
