AXDSPX-FD3

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 2/20/24 INSTAXDSPX-FD3

Google Play Store

Apple App Store

iOS 12.1 or higher

INTERFACE FEATURES

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip-ties • Multimeter

TABLE OF CONTENTS

Installation & Installation Options ........................2

Connections ........................................................3-4

Mobile App .........................................................5-6

Specifications .........................................................7

• Includes a DSP (Digital Signal Processor)

• Selectable 31 Band Graphic EQ or 5 Band Parametric EQ

• 10 individually assignable outputs

• Independent equalization on each of the 10 outputs

• Independent high pass, low pass, and band pass filters

• Each channel can be delayed independently up to 10ms

• Designed for non-amplified models

• Easy behind the radio installation with pre-wired harness

• Bass knob included for level control of subwoofer amp

• Settings adjusted via Bluetooth

®

in a smart device application (tablet

or mobile phone), compatible with both Android and Apple devices

• Read, write, and store configurations for future recall

• Password protect feature available in the mobile app

• USB Micro B updatable

APPLICATIONS

Visit AxxessInterfaces.com for current application list

INTERFACE COMPONENTS

• AXDSPX-FD3 interface

• AXDSPX-FD3 interface harness

• AXDSPX-FD3 vehicle T-harness • Bass knob

Ford DSPX Interface (for Non-Amplified Vehicles

with Pre-Wired Harness)

2020-Up

www.MetraOnline.com

MetraOnline.com may be used to assist

with dash assembly instructions. Simply

enter your Year, Make, Model vehicle

into the vehicle fit guide and look for the

Dash Kit Installation Instructions.
