AXDSPX-WR

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 7/30/20 INSTAXDSPX-WR

Google Play Store

Apple App Store

iOS 12.1 or higher

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties • Multimeter

TABLE OF CONTENTS

Preface ....................................................................2

Installation Options ...............................................2

Installation .............................................................3

Connections

- Aftermarket radio system ..................................4

- Adding a subwoofer to an existing radio .........5

- Full range system to an existing radio ..............6

AXDSP-X app .....................................................7-16

Pinout ....................................................................17

Specifications ........................................................18

Axxess 10-Channel Digital Signal Processor

with Water Resistant Case

• Water resistant enclosure with zip tie mounts included

• 31 Band graphic EQ

• 6 Inputs, 10 individually assignable outputs

• Independent equalization on each of the 10 outputs

• Independent high pass, low pass, and bandpass filters

• Each channel can be delayed independently up to 10ms

• Easy behind the radio installation in most applications

• Designed for motorcycle and UTV applications

• Clipping detection and limiting circuits

• Bass knob included

•

Settings adjusted via Bluetooth® in a smart device application (tablet

or mobile phone), compatible with both Android and Apple devices

• Read, write, and store configurations for future recall

• Password protect feature available in the mobile app

• Micro-B USB updatable

• AXDSP-X circuit board • AXDSPX-WR harness (with gaskets)

• AXDSPX-WR enclosure (w/ case, cap,and O-ring)
