Installation instructions for AXHUB-1

REV. 2/3/2020 INSTAXHUB-1

axxessinterfaces.com

•

metraonline.com

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Axxess Integrate

CAUTION!

Metra recommends disconnecting the negative battery terminal before beginning any instal-

lation, unless the vehicle manufacturer recommends against so. Please check with your local Dealership

for more information. All accessories, switches, climate controls panels, and especially air bag indicator

lights must be connected before reconnecting the battery or cycling the ignition. Also, do not remove the

factory radio with the key in the on position, or the vehicle running. It would be best to remove the key

from the ignition and then wait a few seconds before removing the factory radio.

• Allows the ability to update Axxess interfaces from

most mobile devices

• Allows updates from iOS devices

• Allows updates from Android devices

• Freedom to update without a computer

• Must be connected to either a cellular network,

or Wi-Fi hotspot to update

• Allows changes to be made to the AXSWC (dual assign, force

radio, reassign buttons)

FEATURES

AXHUB-1

(to be used along with the Axxess Updater app)

APPLICATIONS

• Axxess hub interface • DC power cable with

cigarette lighter adapter • 4-pin to 4-pin Bootloader update cable

• Micro “B” USB update cable

INTERFACE COMPONENTS

• Android mobile devices • iOS mobile devices

Bootloader 4-pin

cable interface

DC car power input

Mobile device

USB input

Micro USB

input

• Connect the DC power cable into

the AXHUB-1 and then into the

vehicles DC plug.

Note:Depending on the vehicle,

the ignition may need to be on to

provide power to the AXHUB-1.

• Connect the USB SYNC cable,

provided with your mobile device, to

the USB port located on the RIGHT

side of the AXHUB-1.

(Continued on the next page)

Connections to be made
