AXPIO-JT1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 7/5/22 INSTAXPIO-JT1

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Panel removal tool • Phillips screwdriver

• Torx screwdriver

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Assembly

- Radio provision ...................................................2

- Pioneer Modular DDIN radio provision ..............3

AXXESS Interface Installation ...........................4-16

Jeep

Gladiator JT 2020-Up

Note: This kit will function in both Single-Zone and Dual-Zone vehicles:

• All HVAC functions will be retained.

•

Single-Zone vehicles will only get status feedback of the HVAC functions,

while Dual-Zone vehicles can also be controlled through the radio screen.

• Compass is only retained on vehicles equipped with the UConnect 3

(5" touchscreen).

• The External Speaker is only required in vehicles with safety group features.

Attention! Designed specifically for Pioneer’s DMH-W4600NEX/WC4660NEX.

Pioneer 9" DMH-WC6600NEX will require the Metra Floating Mount Kit

109-UN02. (sold separately)

KIT COMPONENTS

• A) Radio bezel • B) Shallow mount brackets • C) Modular radio brackets • D) Panel clips (4)

ABCD

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Included with Kit

Antenna Adapter:

Included with Kit

GPS

Antenna Adapter:

Included with Kit

Visit AxxessInterfaces.com for up-to-date

vehicle specific applications.
