AXRC-GMLN10

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 1/10/22 INSTAXRC-GMLN10

Product Info

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

NOTE: Refer to the instructions included with

the aftermarket radio.

OPTIONAL ACCESSORIES (sold separately)

Extension Harness: AXEXH-GM10

TABLE OF CONTENTS

Connections ............................................................2

Installation .............................................................3

Programming .........................................................3

APPLICATIONS

INTERFACE COMPONENTS

• AXRC-GMLN10 interface

• AXRC-GMLN10 harness

(1)(2) With RPO code I0B • With RPO code I0A

The , if applicable, are in the in the following locations:: Malibu IOA/IOB codesService Parts Identification labels Rear Compartment Floor

Glovebox: Canyon/Colorado/Cruze/Equinox/Silverado/Sierra Note: RPO (QR codes) are in the driver door jam or on the label.“B Pillar”VIN

GM Data Interface2016-2019

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip-ties

CHEVROLET

Colorado 2017-2019(1)

Cruze 2016-2019(2)

Cruze Hatchback 2016-2019(2)

Equinox 2018(1)

Malibu 2016-2019(2)

Silverado 2016-2018(1)

Silverado LD 2019(1)

Trax 2017-2020(2)

GMC

Acadia 2017-2019(1)

Canyon 2017-2019(1)

Sierra 2016-2018(1)

Sierra Limited 2019(1)

Visit AxxessInterfaces.com for vehicle specific applications.

INTERFACE FEATURES

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

•

Provides illumination, parking brake, reverse, and speed sense outputs

• Used in non-amplified models, or when bypassing a factory amp

• Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Retains factory backup camera

• USB Micro-B updatable
