AXTC-HN1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 6/6/24 INSTAXTC-HN1

INTERFACE FEATURES

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections2 ............................................................

Programming3 .........................................................

Troubleshooting.....................................................4

Honda SWC (Steering Wheel Control)

and Data Interface 2016-2021

APPLICATIONS

• Provides illumination, parking

brake, reverse, and speed

sense outputs

• Retains the factory backup

camera, and also includes an

12-volt to 6-volt step-down

converter (AXCSD-6V)

• Retains audio controls on the

steering wheel

• Designed to be compatible

with all major radio brands

• Auto detects vehicle type, radio

connection, and preset controls

• Ability to dual assign steering

wheel control buttons

• Retains memory settings even

after battery disconnection or

interface removal (non volatile

memory)

• Micro-B USB updatable

Honda

Civic (Coupe, Sedan) LX, LX-P2016-2021 .........................................................

Civic (Hatchback) LX, Sport2017-2021 .............................................................

Fit 2018-2020 ....................................................................................................

INTERFACE COMPONENTS

• AXTC-HN1 interface

• AXTC-HN1 harness

• 3.5mm adapter

•

AXCSD-6V

Product Info

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the ignition

to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

Visit for more detailed information about the product and up-to-AxxessInterfaces.com

date vehicle specific applications.
