AXUSB-NI1
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/31/20
Introduction
The AXUSB-NI1 is used when you want to retain the OE USB port on select
Nissan vehicles (radio utilizes rear USB input). In addition we included RCAs
to allow the user to retain their factory installed 3.5mm jack. (Aftermarket
radio must have Aux in)
1. White Connect the RCA to your aftermarket radio left AUX in (if equipped)
2. Red Connect the RCA to your aftermarket radio right AUX in (if equipped)
3. Connect the USB to the rear USB of the aftermarket radio (if equipped)
Note: Audio devices connected through the 3.5mm jack will be
controlled from the audio device, not the aftermarket radio.
AXUSB-NI1
USB adaptor for select Nissan vehicles
NISSAN
Cube 2011-2012
Juke 2011-2013
NV 2012
Versa 2011-2012
APPLICATIONS
