BEHRINGER MICROPOWER PS400

WELCOME TO BEHRINGER

Thank you for showing your confidence in us by purchasing the

BEHRINGER MICROPOWER PS400. Use this ultra-compact phantom

power supply with mixers and microphone preamplifiers that do not

include phantom power sources. The PS400:

Vsupplies phantom power (+12 V or +48 V) to any type of

condenser microphone

Vroutes the microphone signal to a mixer or

a microphone preamplifier

Please read the safety instructions that appear at the

end of this document.

CONNECTORS AND CONTROL ELEMENTS

This section illustrates and describes each PS400 connector and

control element.

13

45

2

Fig. 1: PS400 connectors and control elements

12 Vconnector:

To connect the power supply unit to the PS400, use the

12 V connector. Connecting the power supply unit to the

mains automatically switches the PS400 on. To disconnect

the unit from the mains, pull out the main cord plug.

ON LED:

As soon as the unit is connected to the mains, the ON LED is

illuminated.

MIC INPUT connector:

To send a microphone signal to the PS400, you need an

audio cable that includes XLR connectors. Plug:

Vone XLR connector into the MIC INPUT connector

Vthe other XLR connector into the condenser microphone

MIC THRU connector:

To route the microphone signal from the PS400 to a mixer

or a microphone preamplifier, you need an audio cable that

includes XLR connectors.

Plug:

Vone XLR connector into the MIC THRU connector

Vthe other XLR connector into the mic input of a mixer or,

alternatively a microphone preamplifier

+12 V / +48 V PHANTOM VOLTAGEswitch:

To select the voltage that you need, push this switch toward

+12 V+48 Vor, alternatively . For details about what value

to use, refer to instructions from the microphone

manufacturer.

SERIAL NUMBER: To register the unit, use the serial number that is

located on the bottom of the PS400.

SETUP EXAMPLE

The following is an example of how to set up the PS400:

PROMIXER DJX700

MICROPOWER PS400

STUDIO CONDENSER

MICROPHONE C-1

MIC INPUT

MIC THRU

Fig. 2: PS400 setup example

WARRANTY

For our current warranty terms, please refer to our website at

http://www.behringer.com.
