Universal Wireless DMX
Page 2
Colorise™ Quadra Manual Rev. C © 2016 Blizzard Lighting, LLC
TABLE OF CONTENTS
Colorise™ Quadra 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t run with scissors!) 4
2. Meet The Colorise™ Quadra LED Par 5
Main Features 5
DMX Quick Reference 5
The Colorise™ Quadra Pin-up Picture 6
3. Setup 7
Connecting A Bunch Of Colorise™ Quadra Fixtures 7
Data/DMX Cables 7
Setting the DMX Input Connector as the Active DMX Input 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
Using the AnyFi™ Wireless DMX Receiver 10
Setting the Fixture to Receive Wireless Signal 10
Resetting The Wireless 10
Select W-DMX™ or Standard 2.4GHz Receiver 10
Successful W-DMX™ Connections 11
Skywire™ 6/7-Channel Modes: Selecting the Channel Group 11
4. Operating Adjustments 12
Navigating The Control Panel 12
Control Panel Menu Structure 13
DMX Mode 14
Set the Starting DMX Address 14
Setting the DMX Channel Mode 14
Slave Mode 14
Dimming Mode Settings 14
LED Display On/Off and Menu Lock 14
Custom Programs 15
Auto, Speed, and Sound Active Modes 15
Color Calibration Settings 16
Custom Static Colors & Preset Colors 16
Fixture Reset Functions 17
Data Sync Feature 17
Fixture Information 17
DMX Value In-Depth Reference Guide 18
DMX In-Depth Reference 19
5. Appendix 20
A Quick DMX Lesson 20
Troubleshooting 20
Keeping Your Colorise™ Quadra As Good As New 21
Returns (Gasp!) 21
Shipping Issues 21
Tech Specs 22
Dimensional Drawings 23
Page 3
Colorise™ Quadra Manual Rev. C © 2016 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Colorise™ Quadra Professional LED PAR Fixture
• An Ever-So-Handy Power Cord
• One Really Classy DMX Cable
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on the purchase of your new totally sweet Colorise™ Quadra LED par
xture. She’s a real stunner alright, denitely the cat’s pajamas! Now that you’ve got
your Colorise™ Quadra (or hopefully, ), you should carefully unpack the box Colorises!
and check the contents to ensure that all parts are present and in good condition. If
anything looks as if it has been damaged in transit, notify the shipper immediately and
keep the packing material for inspection. Again, please save the carton and all packing
materials. If a xture must be returned to the factory, it is important that the xture be
returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly off a switched circuit and cannot be run off a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that
the xture you receive is suitable for your local power supply. See the label on the
xture or refer to the xture’s specications chart for more information. A xture’s
listed current rating is its average current draw under normal conditions. Check the
xture or device carefully to make sure that if a voltage selection switch exists that it is
set to the correct line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied
does not match the voltage indicated on the voltage selector switch. All
xtures must be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, please just visit our website at www.blizzardlighting.
com/support and open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are subject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability
for any errors or omissions that may appear in this user manual. Blizzard Lighting™
reserves the right to update the existing document or to create a new document to
correct any errors or omissions at any time. You can download the latest version of this
document from www.blizzardlighting.com.
Author: Date: Last Edited: Date:
J. Thomas 8/20/2015 J. Thomas 6/30/2016
