Sensemore Mode

Our proprietary technology engineered to

further improve the hearing of speech and

spoken dialog by boosting not only vocal

frequency range, but also better amplication

of surrounding sound beyond the conventional

transparency mode.

Follow the steps below to further personalize

the feature:

1. Pair Creative Sensemore Air to the Creative

app by following the in-app instructions

2. Upon successful pairing, tap on the Noise

Control module on the Creative app’s

dashboard

3. Tap and drag on the slider to adjust the level

of ambient sound you’d like to let into the

earbuds. Changes made will be saved and

applied in real time

Active Noise Cancellation (ANC)

Stay focused and rid distractions with ANC,

which cancels out ambient sound from your

environment, creating the perfect seal in your

ears while reducing unwanted background

noises.

Follow the steps below to further personalize

the feature:

1. Pair Creative Sensemore Air to the Creative

app by following the in-app instructions.

If you have already done so, proceed to

step 2

2. Upon successful pairing, tap on the Noise

Control module on the Creative app’s

dashboard and ensure that Active Noise

Cancellation is selected

3. Tap and drag on the slider to adjust your

preferred ANC level. Changes made will be

saved and applied in real time

Ambient Mode

Let in just enough of ambient sound into

the earbuds to be more aware of your

surroundings and stay alert to what’s

happening around you without having to

pause your songs.

The Creative Sensemore Air is set to

Sensemore Mode by default. Follow the steps

below to reassign the touch control:

1. Pair Creative Sensemore Air to the Creative

app by following the in-app instructions.

If you have already done so, proceed to

step 2

2. Upon successful pairing, tap on the Noise

Control module on the Creative app’s

dashboard and select Ambient Mode as

your preferred mode

3. Tap and drag on the slider to adjust the

level of ambient sound you’d like to let into

the earbuds. Changes made will be saved

and applied in real time

CONTROLS

Note: Certain playback functions can be customized through the

Creative app when connected via Bluetooth

i) Playback Mode

iii) Entering Bluetooth Pairing Mode Manually

Note: The earbuds can only manually enter Bluetooth Pairing mode

when no audio is being played.

3s3s

iv) Powering On / O Earbuds Manually

OFF

6s6s

3s3s

ii) Call Mode

3s3s

x2x2

OVERVIEW

USB-C Charging Port

Charging Case Battery Indicator

i) Charging Indicator

Solid Red

Solid Yellow

Solid Green

Low

Medium

High

ii) Battery Level

Glowing Red

Solid Green

Charging

Fully Charged

Left Earbud Charging Indicator

Right Earbud Charging Indicator

Glowing Red

Solid Green

Charging

Fully Charged

i) Earbuds Charging Indicator

Earbuds LED Indicator

Blinking Blue

Blinking Red and Blue

Glowing Red (In Charging Case)

Disconnected

Bluetooth

Pairing

Charging

LED OFully Charged

80 x 2 = 160

QUICK START GUIDE

快速入门指南

快速入門指南

󲖸󱿠󲖸󷳋

EN 

使用产品前请阅读使用说明









creative.com/register



creative.com/support

MULTI-LANGUAGE QUICK START GUIDE DOWNLOAD

creative.com/support/SensemoreAir

[FR] TÉLÉCHARGEMENT DU GUIDE DE DÉMARRAGE RAPIDE MULTI-LANGUES

[DE] MEHRSPRACHIGE SCHNELLSTARTANLEITUNG HERUNTERLADEN

[ES] DESCARGA DE LA GUÍA DE INICIO RÁPIDO EN MÚLTIPLES IDIOMAS

[IT] DOWNLOAD DELLA GUIDA DI AVVIO RAPIDO MULTILINGUA

[NL] MEERTALIGE SNELSTARTGIDS DOWNLOAD

[RU] МНОГОЯЗЫЧНОЕ КРАТКОЕ РУКОВОДСТВО ЗАГРУЗИТЬ

[PL] POBIERZ PRZEWODNIK SZYBKIEGO STARTU W WIELU JĘZYKU

[CZ] STÁHNOUT VÍCEJAZYKOVÝ RYCHLÝ NÁVOD K POUŽITÍ

[SK] STIAHNUŤ SI RÝCHLY NÁVOD NA ŠTARTOVANIE VIAC JAZYKOV

[JP] 󲡕󸌫󸑤

[CS] 󲡕󸛓󸌫󳗐󸷀󱮧󹠗󳬘󱻣󱘕󸱠

[CT] 󲡕󸑤󸌫󳗐󸷀󱮧󹝭󳬘󱻣󱘕󸮛

[KO] 󻁓󺫜󼌣󾖴󻯏󻛧󾖴󼁋󼔀󾖴󺥯󼓣󻉋󾖴󻁓󼐣󻗋󻉋

[NO] NEDLASTING AV HURTIGSTARTVEILEDNING FOR FLERE SPRÅK

[FI] MONIKIELINEN PIKA-ALOITUSOPPAAN LATAUS

[SV] FLERSPRÅKIG SNABBSTARTSGUIDE LADDA NER

[DA] DOWNLOAD AF HURTIG STARTVEJLEDNING PÅ FLERE SPROG

Siri Google Assistant

x2 x2

Sensemore

Mode

PERSONALIZING NOISE CONTROL FEATURES

Active Noise

Cancellation

O

EARBUDS FIT GUIDE

Gently push and wiggle the earbuds into the respective ear canal

until a good seal is made to ensure proper tting. Additional pairs of

silicone tips are also provided so users can achieve an optimal t.

2. 4.1. 3.

Creative Sensemore Air supports Qi-enabled wireless charging. To charge both the charging case and earbuds wirelessly, slot the earbuds into the

case’s magnetic charging slots, then place the charging case on the wireless charging pad*. Do note that the earbuds cannot be charged wirelessly

without its charging case.

*Wireless charging pad not included

CHARGING CREATIVE SENSEMORE AIR WIRELESSLY

MASTER RESET

Touch the earbuds and hold for 5s while they are in the charging case. Earbuds will blink once

in blue upon completion of Master Reset. Master Reset is reserved for cases where users

encounter issues while earbuds are in use or during situations such as:

Bluetooth Pairing failure, random LED blinking, failure to pair secondary earbud with the main

earbud, or to reset all data.

Common Connectivity Issues

This article highlights a phenomena and recommendation for music cutting out and earbuds that do not stay connected.

When pairing a smart mobile device with the earbuds, the signal is strongest when there is a line-of-sight between the pairing devices.

If the signal passes through the body, which is mostly made up of water uid, it may get absorbed, which may result in pairing diculty. If the

mobile device is already connected to the earbuds, it may result in signal lost or the earbuds may get disconnected.

Preventing Oscillating Whistling Noise

When Sensemore Mode or Ambient Mode is enabled, there is a possibility of an oscillating whistling sound produced by the earbuds when the

built-in microphones are blocked or while it’s being held in the palm of your hand. It may also occur when the earbuds are kept away without its

charging case in an enclosed area or through humid conditions and / or perspiration.

To prevent this occurrence,

• Ensure the built-in microphones are not blocked by your palm or hand, and to keep the earbuds dry

• Turn o Sensemore Mode / Ambient Mode before placing the earbuds back in its charging case

• Reduce the level of Sensemore Mode / Ambient Mode via the Creative app

• Ensure that the charging case is adequately charged before placing the earbuds back in its charging case to charge

TECHNICAL SPECIFICATIONS

Headphones Drivers

• 6 mm Bio-cellulose Driver x 2

• Frequency Response: 20–20,000 Hz

Microphones

• Type: Omni-directional x 4

• Frequency Response: 100–10,000 Hz

• Sensitivity (1 kHz): -38 dBV / Pa

Interface

• Qi-compatible wireless charging, USB-C (charging)

Wireless Operating Range

• Up to 10m / 33 ft

• RF Output Power: < 8 dBm

• Operating Frequency: 2402–2480 MHz

Bluetooth Version

• Bluetooth 5.2

Bluetooth Proles

• A2DP (Advanced Audio Distribution Prole)

• AVRCP (Audio / Video Remote Control Prole)

• HFP (Hands-free prole)

Battery

• Earbuds (Left and Right)

Lithium-ion polymer battery:

3.7V 60 mAh 0.222 Wh

• Battery Charging Case

Lithium-ion polymer battery:

3.7V 400 mAh 1.48 Wh

Input Rating

• 5V

Total Playtime

• Up to 35 hours

Charging Time

• 2–3 hours

Audio Codecs

• AAC, SBC

Sweat & Water Resistance for Earbuds

• IPX5

Operating Temperature

• 0–45°C

countries. The Bluetooth

word mark and logo are owned by Bluetooth SIG, Inc. and any use of such marks by Creative Technology Ltd is under license. Siri is a trademark of Apple Inc., registered

in the U.S. and other countries. All other trademarks are the property of their respective owners and are hereby recognized as such. All specications are subject to change without notice. Actual

product may dier slightly from images shown. Use of this product is subject to a limited warranty.

CREATIVE APP

Set up your product, customize playback controls,

personalize audio settings, enhance the product’s

performance, and more with the Creative app.

• Choose between Sensemore Mode and Ambient Mode

• Customize buttons for personalized playback experience

• Adjust noise control level through Sensemore Mode, Ambient

Mode, and Active Noise Cancellation

• Modify audio settings with Graphic EQ

• Perform software upgrades, product registration, and more

Download the Creative App from:
