VESA-Compatible Heavy-Duty
Height-Adjustable Rolling Floor Stand
USER MANUAL
PAD-HFSVP
2. Stand Assembly:
1. Attaching the wheels
x1
x1
x1 x4
Screw in ADD-VPOLE and ADD-POLE as shown above.
3. VESA Pole Assembly to Base:
4. Cable Routing/Cable Management:
4. Mounting Item to VESA plate:
Combine nuts and bolts through VESA plate from the front & back as
shown with provided tools.
Route the cable through the hole at the top of the body and out
the bottom.
Contents:
Instructions:
888-733-4448 888-733-4448
x1
**Enclosure is not included and
shown for example purposes.
**Enclosure is not included and
shown for example purposes.
x4
Screw wheels into floor base by hand,
then use wrench to tighten.
1. Insert the pole into the center of the heavy duty base.
METAL CONNECTION
HEAVY DUTY BASE
HEIGHT
ADJUSTMENT
KNOB
POLE
METAL WASHER &
TIGHTENING SCREW ROD
2. Place metal washer over tightening screw rod, then
screw into the bottom side of the stand base center,
turning clockwise to tighten.
2.Routing Your Charge Cable
1.Set the pole to its lowest position. Insert cable head through bottom pole and push upward.
2. Pinch cable head at top pole opening and extend pole height, keeping cable pinched.
3.Draw cable head out from pole opening.
This product allows you to go through the cable from the cable routings on the pole.
