User Manual
Model: POE15
Multiple PoE Extenders can be connected every 100 meters to
obtain greater distances.The actual figures depend on operating
conditions.The range is over 24AWG or heavier Cat-5e or Cat-6
cable except where specified.
Examples for medium power PoE Devices (that are PoE Class 2,
or require under 6 watts)
Maximum Distances for Power Sources
5
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.
Copyright©Shenzhen Cudy Technology Co., Ltd. All rights reserved.
EU Address: Otto esser 2c, 65451 Kelsterbach, Germany
EU declaration of conformity
Support and Warranty
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of
directives 2014/30/EU, 2014/35/EU, 2009/125/EC and
2011/65/EU.The original EU declaration of conformity may be
found at http://www.cudy.com/
810600063
Examples for full power PoE Devices (that are PoE Class 0 or 3, or
require under 12 watts).
Examples for PoE+ Devices (that are PoE Class 4 that under 22
watts, or 802.3at compliant).
PoE Source Maximum Distances
PoE switch
(802.3af,Output voltages 50V) 200M
200M
300M
300M
15W mid-span
(802.3af,Output voltages 50V)
PoE+ switch
(802.3at,Output voltages 50V)
30W mid-span
(802.3at,Output voltages 50V)
PoE Source Maximum Distances
PoE switch
(802.3af,Output voltages 50V) Not applicable
Not applicable
200M
200M
15W mid-span
(802.3af,Output voltages 50V)
PoE+ switch
(802.3at,Output voltages 50V)
30W mid-span
(802.3at,Output voltages 50V)
Model
No. of channels
Pass Through
Data Rates
POE15
Power over
Ethernet input
Pin Assignment and Polarity:
Both 1/2, 3/6 and 4/5, 7/8
Power over
Ethernet Output
Pin Assignment and Polarity: 1/2 (+), 3/6 (-)
Output Power: up to 25W
1(PoE IN) into 1(PoE OUT)
10/100/1000 Mbps half/full duplex
Mounting
Environment
Operating Humidity
Storage Temperature
Storage Humidity:
Operating Ambient
Temperature
Wall or shelf
Indoor or Outdoor
Regulatory Compliance
-10 to45℃
-20 to 60℃
Maximum 95%, Non-condensing
IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
Maximum 90%, Non-condensing
Dimensions 145mm x 60mm x 40mm
Connectors
Network cables
Shielded RJ-45, EIA568Aand 568B
Shielded category 5 (or higher)
Specifications
4
Features
3
Description
2
Hardware Connection
1
Support up to 3 PoE+ Extenders for 400 Meters Distance
PoE+ Extender CameraPoE+ Switch
MAX 100Meters MAX 100Meters
PoE+ Extender PoE+ Extender PoE+ Extender CameraPoE+ Switch
100Meters 100Meters 100Meters 100Meters
Cudy Outdoor Gigabit PoE+ Extender helps install PDs (such as
IP Security Cameras, wireless access points) at greater distances
than 100 meters. By connecting PoE+ Extender for every extra
100 meters of cable, both Ethernet and PoE can be extended to
up to a total distance of 200 meters. It does not require any
additional power supply , the connected PDs is fed by an single
PoE switch or mid-span, which simplifies installation.
Cudy Outdoor PoE+ Extender has an IP67 waterproof enclosure
and includes waterproof connectors on both the input and
output sides. With surge protection function, working
temperature is -25 ° C to 55 ° C, can withstand severe weather.
IP67 waterproof enclosure for outdoor use
IEEE802.3at / IEEE802.3af Compliant
10/100/1000Mbps Ethernet Ports
Wall-Mount design for any application scenario
Easy plug-and-play installation
No additional power supply is required
One PoE extender extends additional 100 meters for PoE network
Support up to 3 PoE Extenders for a total extension of 400 meters
