Oldal 1/2

1
Features
IEEE802.3af/802.3at/802.3bt compliant
One gigabit PoE input port (60 watts max)
Four gigabit PoE output ports (30 watts max per port)
Extends PoE signal for additional 100 meters
No additional power supply required
Automatically detects PoE and Non-PoE equipments
Desktop or wall-mount installation
Metal case, plug and play
4-Channel
Gigabit PoE++ Extender
User manual
4-Channel Gigabit PoE++ Extender
4-Channel Gigabit PoE++ Extender
IEEE802.3bt/at/af compliant,
support up to 60 watts PoE power input
IEEE802.3at/af compliant,
support up to 30 watts PoE power output per port
1 PoE IN
→
4 PoE OUT

Indicators
Connectors
Network cables
Dimensions
Mounting
Environment
Environmental Conditions
Regulatory Compliance
Application
32
Item Description
No.of channels 1(PoE IN) into 4(PoE OUT)
Pass Through Data Rates
Power over Ethernet Input
Power over Ethernet Output
Features
Gigabit Switch
60W PoE Injector
POE 40
Data+Power 100Metres
Data+Power 100Metres
4-Channel Gigabit PoE++ Extender 4-Channel Gigabit PoE++ Extender
Pin Assignment and Polarity:1/2 (+), 3/6 (-)
Output Power: up to 12W for 4 PSE or
30W for 2 PSE
LED indicators are located on the RJ45
connector Power indicator: PoE enabled
Powered success:Power
Network indicator: Link/Act
10/100/1000 Mbps half/full duplex
Shielded RJ-45, EIA 568A and 568B
Shielded category 5E (or higher)
119mm x 85mm x 28mm
Wall of shelf
Indoor
IEEE 802.3af (15.4W)
IEEE 802.3at (30W)
IEEE802.3bt 4Pairs(60W)
Operating Ambient Temperature:0 to 40℃
Operating Humidity:
Maximum 90%, Non-condensing
Storage Temperature:-40 to 70 ℃
Storage Humidity:
Maximum 95%, Non-condensing
Pin Assignment and Polarity:
Both 1/2, 3/6 and 4/5, 7/8
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the essential requirements and
other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC and
2011/65/EU.The original EU declaration of conformity may be found at
http://www.cudy.com/
For support and warranty, please visit: http://www.cudy.com/. Specifications are subject to
change without notice. Cudy is a registered trademark of Shenzhen Cudy Technologies
Co., Ltd. Other brands and product names are trademarks or registered trademarks of their
respective holders.
Copyright©Shenzhen Cudy Technology Co., Ltd. All rights reserved.
EU Address: Otto esser 2c, 65451 Kelsterbach, Germany
Support and Warranty
