Argus 60 optical swing lane

Entrance systems

Subject to change without notice

The definition of elegance

Basic equipmentArgus 60

ConstructionInterlock height39” (990)

Interlock length64-15/16” (1650)

Passage width25-9/16” (650)

Total width41-3/4” (1060)

Housing, base columns,

guiding elements

Profile and inlay elements in the hand rails and

in the front of the side panels are made of

aluminum.

Blocking elementsTwo door leaves made of transparent plexiglass,

upper edge 39” (990).

SensorsThe sensor system is integrated in the guiding

elements both horizontally and vertically.

FinishSurface combinations according to presetting or

individual.

FunctionDrivesType 2.* Integrated in the swing tube. Safety

level 2. Passage area monitored by enhanced

sensor system with an optimized installation

length and arrangement (increased level of

single passage monitoring in both directions,

including detection of opposite direction).

Operation modesNormal operation is leaves closed. The door

leaves open in the direction of passage, once

authorized and then close again.

Electric componentsControl system and power supply integrated in

the unit.

Power supply100–240 VAC, 50/60 Hz, 300 VA

Standby power

consumption

17 VA

Standard adjustment in

case of power failure

Door leaves move freely.

InstallationDowelled on finished floor level FFL.

Not suitable for outdoor installation.

*Type 2: power-assisted motion; two servo-positioning drives/electrically closed in both directions.

Argus 60 is a longer model

(64-15/16” [1650]) offering an

increased safety level with a vertical

strip installed as an additional

scanner. Optional full height door

leaves offered increased security. An

easy-to-understand user guidance

system with optional intuitive cueing

lights in the top cover and colored

light signals directly on the card

reader ensures a high level of

convenience. Ambient lighting is

integrated for aesthetics—the unit

becomes a real highlight in the foyer.
