KlavisMixwitch user manual V1.1 Page 1 of 11

MixwitchMixer & Switcher

Voltage & clock-controlled analog switch with mixer

Introduction

Focused versatility seems an oxymoron when describing the features that led us to design the

Mixwitch. With only a pinch of mixing, inverting and controlled switching, we brew up a plethora

of combinations and uses. This is voltage processing magic!

Mixwitch

Mixer & switcher

A1A2

Switcher

CV

Clk

B

CV/Clk

B1B2

In B1In B2B

In A1In A2

A

Klavis

Off

Log

Log

Off

Features at a glance

Dual 2 to 1 mixers, normalized into 4 to 1

oClick-less mute per mixer

oClick-less polarity inversion per input with LED

indication

oModulation vs. audio mode selection (lin/log) per

mixer, with change of potentiometer curve response

and LED indication.

oTwo LEDs on each output showing the amplitude and

polarity of the output signal

oUnconnected inputs present a fixed voltage to ease

offset creation

oFull range DC-coupled analog signal path

Switch /Selector

oSwitch among 4 inputs, only 2, or disabled

oSelect an input sequentially with a clock/trigger

oSelect an input randomly with a clock/trigger

oSelect an input in relation to a control voltage

oCV and clock control are audio rate capable

Settings retained over the power cycle

High-quality potentiometers with metal shaft

Skiff-friendly & compact module
