P/N: 2900-301287 Rev 1 www.KramerAV.com
USER MANUAL
MODELS:
TP-873XR HDMI 4K Line Transmitter
TP-874XR HDMI 4K Line Receiver
Kramer Electronics Ltd.
TP-873XR / TP-874XR Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Defining TP-873XR HDMI 4K Line Transmitter 4
TP-873XR HDMI 4K Line Transmitter 4
TP-874XR HDMI 4K Line Receiver 5
Mounting TP-873XR/TP-874XR 6
Connecting TP-873XR/TP-874XR 7
Connecting to TP-873XR/TP-874XR via RS-232 8
Wiring the RJ-45 Connectors 8
Setting the DIP-Switches 9
Technical Specifications 10
Kramer Electronics Ltd.
TP-873XR / TP-874XR Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to www.kramerav.com/downloads/TP-873XR or
www.kramerav.com/downloads/TP-874XR to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving the Best Performance
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
Do not secure the cables in tight bundles or roll the slack into tight coils.
Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
Position your Kramer TP-873XR or TP-874XR away from moisture, excessive sunlight
and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
Warning:
Use only the power cord that is supplied with the unit.
To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which located on the bottom of the unit.
