10.

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This Quick Guide covers the model: CRS305-1G-4S+OUT.

This is a network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up to date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

First steps:

First steps:First steps:

Connect your PC to any Ethernet port.

Connect the power adapter to the DC jack.

Set the IP for your PC to 192.168.88.2

The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility or Web browser.

Use Winbox or a Web browser to connect to the default IP address of 192.168.88.1 from any port, with the username admin and no password (or, for

(or, for

(or, for (or, for

some models, check user and wireless passwords on the sticker).

some models, check user and wireless passwords on the sticker).some models, check user and wireless passwords on the sticker).

We recommend clicking the “Check for updates” button and updating your RouterOS software to the latest version to ensure the best performance and

stability. The device needs to have an active internet connection.

To manually update the device go to our webpage and download the latest software version packages.

Open Winbox and upload them to the Files menu.

Reboot the device.

Set up your password to secure the device.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only accessories approved by the manufacturer, and which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

We highly recommend using AC/DC power supply only for indoor use cases.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures

Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
