EN - English -Quick Guide:

This "hAP ax³" series Quick Guide covers models: C53UiG+5HPaxD2HPaxD (hAP ax³).

This is a wireless network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most relevant technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, brochures, and more info about products at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

If you need help with configuration, please seek a consultanthttps://mikrotik.com/consultants

First steps:

Please attach provided antennas to the device, before connecting to the power

source;

Make sure your Internet service provider is allowing hardware change and will issue

an automatic IP address;

Connect the service provider cable to the Internet port and connect the device to the

power source;

Open network connections on your computer and search for MikroTik wireless

network - connect to it;

The configuration can be done through the wireless network using a web browser or

mobile app. Alternatively, you can use a WinBox configuration tool ;https://mt.lv/winbox

Open in your web browser to start configuration, user name: ahttp://192.168.88.1

dmin

and there is no password by default (or, for some models, check user and wireless

passwords on the sticker);

Click the "Check for updates" button and update RouterOS to the latest version;

For a manual update of the device, visit the products page at to find your product. The required packages are accessible under https://mikrotik.com/products

the menu;

"Support&Downloads"

Upload downloaded packages to the menu and reboot the device;

WebFigor



Winbox



"Files"

By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;

In the menu set up the following: Choose your country, to apply country regulation settings;

"QuickSet"

Set up your wireless network password in the left field;
