EN - English -Quick Guide:

This Quick Guide covers the model: C52iG-5HaxD2HaxD-TC.

This is a wireless network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most relevant technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, brochures, and more info about products are at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

If you need help with configuration, please seek a consultanthttps://mikrotik.com/consultants

First steps:

;Ensure your Internet Service Provider (ISP) allows hardware changes and automatically assigns an IP address

Connect the ISP cable to the Ethernet1 port;

Connect the device to the power source;

Connect to the device through any of the ports, excluding Ethernet1, or the wireless network "MikroTik-..." (ensure to check the wireless passwords on the

sticker);

Establish a connection using a mobile application.Alternatively, use Webfig in a web browser or the "WinBox" configuration tool at;https://mt.lv/winbox

Start configuration within the chosen tool, using the default IP address 192.168.88.1. If the IP address is unavailable, use Winbox and choose the "Neighbors"

tab to find the device;

Proceed to connect using the MAC address. The username is "admin," and there is no password (or, for some models, check user and wireless passwords on

the sticker);

Click the "Check for updates" button and update RouterOS to the latest version;

For a manual update of the device, visit the products page athttps://mikrotik.com/productsto find your product. The required packages are accessible under 

the "Support&Downloads" menu;

Upload downloaded packages to the WebFig or Winbox "Files" menu and reboot the device;

By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;

In the "QuickSet" menu set up the following: Choose your country, to apply country regulation settings;

Set up your wireless network password in the left field;

Set up your router password in the bottom field.

This device needs to be upgraded to RouterOS v7.11.2 or the latest stable version, to ensure compliance with local authority regulations!

It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
