Model: MCT-156QDS, MCT-156QDS-POE, MCT-156HPQ, MCT-156HPQ-POE
Please keep this manual for future reference.
TABLE OF CONTENTS
PAGE
DECLARATION……………....…………………..............……………............…....1
PRODUCT INSTRUCTIONS……….......……..............…………………....………………1
POWERING ON THE PRODUCT………...........………………………...….....….……….2
INSERTING THE SD CARD.....………………….................………………………………2
INSERTING USB DEVICES……………..................……………......…………….……….2
HOME SCREEN.......………..…………….....................………….…......................……3
SYSTEM BAR….........................................................................................................6
APPLICATIONS.......................................................................................…9
LANGUAGE………………......…............................................................……10
DATE & TIME….…………….....….......….............................…...................................11
VOLUME………………......….......….............................…...................................12
BRIGHTNESS………………......….......…........................................................12
SCHEDULED POWER ON/OFF...................…........................................................13
WI-FI....................………………......….......….............................................17
ETHERNET....................………………......….......….............................................18
BLUETOOTH....................………………..….............................................19
VIRTUAL KEYBOARD....................…....……………......…........................................21
SWITCH INPUT METHODS......................………......….......…................................22
TAKE PHOTOS & SHOTS...............................…......….......…................................23
SURF ONLINE................………………......….......….................................................26
BROWSE FILES................………………......….......…...............................................27
PLAY MEDIA................………………......….......…...................................................28
INSTALL & UNINSTALL APPS................………………........….................................29
INSTALL APPS...................................................……........…......................29
UNINSTALL APPS...............................................................…....................32
RESET TO FACTORY DEFAULT................………....................................................33
Adapt-IQ 15.6” User’s Manual
Declaration
Please read the instructions carefully before equipment installation and
using the device.
Do not put the product in high temperature, humid or dusty environment.
Do not drop, crash or break down this product.
will cause operation system error.
This product is not waterproof.
Use only approved add-on enhancements.
Product Instruction
1. Camera (optional): 2M pixels camera
2. SD Card Slot / Cover: support external SD card
3. Add-on module slot: to put optional add-on module
4. Micro-USB Port: support Micro-USB 2.0
5. VESA Mount Holes: for installing the bracket
6. Speakers: audio output
7. Function Keys (Vol+ / Vol- / Up / Down / Exit)
Back
B ottom
F ront
Top
1 2 3
4
5 6 7 8
14
Mechanical Design
Bottom
1. USB x2
2. Ethernet Ports p2-x2 (RJ45)
3. Micro USB
4. Add on Module Slot
5. Optical Port
6. H
eadphone Jack
7. LAN (POE)
8. Power Barrel Connector
9. Power Switch
Mimo Monitors
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
1
8
9
8. AC/DC In Jack: powered by 12V/3A AC/DC input
9. IR Receiver & LED Indicator
IR Receiver: support remote control
LED Indicator:
Power supply ON
Red then turn Green after kernel boot up.
Power supply OFF
LED light off.
10. USB Port x 2: support USB 2.0 Host type A
11. RS232 Port x 2: in RJ45 connector form
12. S/PDIF Port: support S/PDIF audio output
13. Headset + Microphone Jack
14. 10/100Mbps RJ45 Ethernet Port: support Ethernet connection
15. Power Switch: switch power ON/OFF
Power on the Product
Step 1 Plug the power source into the AC/DC in jack (#8 in Product
Instruction).
Step 2 Switch the power switch (#15) on the bottom of this product to ON.
Insert SD Card
This product supports external SD card. Please insert your SD card into the
SD Card Slot (#2 in Product Instruction) on the top of this product.
Insert USB Devices
This product supports USB and Micro-USB to deal with your files.
USB
Plug your USB memory into the USB port (#10 in Product Instruction) on
the bottom of this product, and then you can do the file operations via the File
Browser. (See in Browse Files).
Micro-USB
Connect the Micro-USB port (#4 in Product Instruction) on the bottom of
this product and the USB port on your computer with a Micro-USB-to-USB
cable.
4
9
10
11
12
4
4
13
Back
4. Add on Module Slot
9. Volume Up/Down
10. Menu Navigation
11. Menu
12. Vesa 75 Mount
13. Speakers
14. GPIO
Mimo Monitors
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
2
