Illustrations may dier from actual product. We are constantly striving to improve our products, therefore
the specifications contained herein are subject to change withoutnotice.
NINJA is a registered trademark in the United Kingdom of SharkNinja Operating LLC.
NINJA WOODFIRE is a pending application in the United Kingdom of SharkNinja Operating LLC.
© 2023 SharkNinja Operating LLC
OG751ANZ_IB_MP_Mv9
TECHNICAL SPECIFICATIONS
Voltage: 230V~ 50Hz
Power: 1760W
RECORD THIS INFORMATION
Model Number: ____________________
Serial Number: _____________________
Date of Purchase: ___________________
(Keep receipt)
Store of Purchase: __________________
REGISTER YOUR PURCHASE
ninjakitchen.com.au/apps/product-registration
ninjakitchen.co.nz/apps/product-registration
Scan QR code using mobile device
THANK YOU for purchasing this product
AUS +61 2 8801 7666 | NZ +64 800 112 660
PRODUCT REGISTRATION:
Please visit ninjakitchen.com.au | ninjakitchen.co.nz to register your new Ninja® product within
28 days of purchase. You will be asked to provide the store name, date of purchase and model
number along with your name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification.
Mann&Noble Pty Ltd
Building D, 33 Quarry Road
Erskine Park NSW, Australia, 2759
AU ninjakitchen.com.au | NZ ninjakitchen.co.nz
AUS +61 2 8801 7666 | NZ +64 800 112 660
NINJA WOODFIRE ELECTRIC
BBQ GRILL & SMOKER
OG751ANZ | Instructions
IMPORTANT SAFETY INSTRUCTIONS
OUTDOOR HOUSEHOLD USE ONLY. READ ALL INSTRUCTIONS BEFORE USE
WARNING Failure to follow these instructions could result in electric shock, fire or
burn hazard which could cause property damage, personal injury, or death. When using electrical
appliances, basic safety precautions should always be followed, including the following:
1 To eliminate a choking hazard for young children, discard all packaging materials immediately upon unpacking.
2 This appliance is for outdoor household use only. DO NOT use this appliance for anything other than its
intended use. DO NOT use in moving vehicles or boats. Misuse may cause injury.
3 DO NOT use indoors. This grill is designed for OUTDOOR USE ONLY in a well-ventilated area. If used under
any overhead cover, toxic fumes, including carbon monoxide, may accumulate and cause serious bodily injury
or death.
4 This appliance can be used by persons, including children, with reduced physical, sensory, or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
5 ALWAYS ensure the appliance is properly assembled before use. DO NOT use without side handles attached.
6 To avoid property damage from flame or heat maintain a minimum distance of 92cm (3 feet) from rear, sides
and top to walls, rails or other combustible constructions.
7 Ensure the surface is level, stable, clean and dry. DO NOT place the appliance near the edge of the surface the
grill is placed on during operation.
8 Children should be supervised to ensure that they do not play with the appliance. Keep the appliance and its
cord out of reach of children. DO NOT allow the appliance to be used near, cleaned or maintained by children.
9 The appliance should be supplied through a residual current device (RCD) having a rated residual operating
current not exceeding 30mA. The appliance is to be connected to a socket-outlet having an earthing contact.
10 A short power-supply cord is provided to reduce the risk of children less than 8 years grabbing the cord or
becoming entangled and to reduce the risk of people tripping over a longer cord. SUITABLE FOR USE WITH
OUTDOOR APPLIANCES. Longer detachable power-supply cord or extension cords are available and may be
used if care is exercised in their use.
11 To avoid property damage and burn injury from flame or heat, ALWAYS maintain a minimum safe distance of
at least 1 foot (30 cm) from the pellet box during smoking. Small flames can come out from the pellet box if
the grill lid is lifted in windy conditions.
12 To avoid burn injury, ALWAYS use pellet scoop when adding pellets to smoker box. DO NOT add pellets by
hand.
13 To avoid burn injury and property damage, make sure the lid of the smoke box is fully closed to prevent
flames from escaping out of the smoke box.
14 Pellets may continue to burn after cook time is complete. Do not touch or remove the smoke box until the grill
has stopped smoking, pellets have completely burnt out and the smoke box has cooled.
15 To avoid personal injury and burns allow to cool before cleaning, disassembly, putting in or taking off parts
and storage.
Read and review instructions to understand operation and use of product.
Indicates the presence of a hazard that can cause personal injury, death or substantial
property damage if the warning included with this symbol is ignored.
Avoid contact with hot surface. Always use hand protection to avoid burns.
For outdoor use only.
Resistant to water splash from any direction.
IPX4
21
AUS +61 2 8801 7666 | NZ +64 800 112 660
ninjakitchen.com.au | ninjakitchen.co.nz
16 DO NOT allow pellets to overflow the pellet box. Doing so will introduce oxygen leading to combustion,
flame and damage to the unit which may result in burn injury.
17 DO NOT touch hot surfaces. Appliance surfaces are hot during and after operation. To prevent burns or
personal injury, ALWAYS use protective hot pads or insulated oven gloves and use available handles and
knobs.
18 DO NOT touch accessories during or immediately after cooking. The basket will become extremely hot
during the cooking process. Avoid physical contact while removing the accessory from the appliance. To
prevent burns or personal injury ALWAYS use care when using with product. We recommend use of long
handed utensil and protective hot pads or insulated oven gloves.
19 ALWAYS ensure the grill is completely cool before releasing and removing the cooking plates or moving
the to avoid burns or personal injury.
20 DO NOT use the appliance without the grill plate installed.
21 To protect against electric shock, cord and extension cord should be arranged so that they will not drape
over the worktop or table top where they can be pulled on by children or tripped over. Keep the cord
connection dry and DO NOT immerse cord, plugs or main unit housing in water or other liquid.
22 Regularly inspect the appliance and power cord. DO NOT use the appliance if there is damage to the
power cord or plug. If the appliance malfunctions or has been damaged in any way, immediately stop use
and call Customer Service.
23 NEVER use socket below worktop surface.
24 NEVER connect this appliance to an external timer switch or separate remote-control system.
25 DO NOT place appliance and let cord touch hot surfaces.
26 Only use recommended accessories included with this appliance or authorised by SharkNinja. The use of
accessories or attachments not recommended by SharkNinja may cause a risk of fire or injury.
27 Before placing any accessory into the cooker, ensure it is clean and dry.
28 DO NOT move the appliance when in use.
29 DO NOT cover the air intake vent or air outlet vent while unit is operating. Doing so will prevent even
cooking and may damage the unit or cause it to overheat.
30 DO NOT place anything on top of the product when the lid is closed during use.
31 Ensure the grill plate is correctly inserted and securely locked into position.
32 DO NOT use this appliance for deep-frying.
33 Some foods may cause oils or grease to splash. Use care when opening the grill to avoid burns.
34 Should a grease fire occur or the unit emits black smoke, unplug immediately. Wait for smoking to stop
before removing any cooking accessories.
35 Socket voltages can vary, affecting the performance of your product. To prevent possible illness, ALWAYS
use an external food thermometer to check that your food is cooked to the recommended temperatures.
36 Use ONLY genuine food grade wood pellets from Ninja in your unit.
37 NEVER use heating fuel pellets, hardwood, charcoal, liquid fuels or any other combustible material in the
Smoker.
38 Keep hands and face away from Smoker Box when unit is in use and hot.
39 ALWAYS keep a fire extinguisher suitable for electrical fires accessible while operating the smoker.
40 ALWAYS store wood pellets in a dry location, away from heat-producing appliances and other
fuel containers.
41 Keep your grill clean and do not allow excess grease or ash to collect inside or on the smoke box and
cartridge. Doing so significantly increases the chances of a grease fire and additional smoke which can
taint the flavour of your food.
42 Please refer to the Cleaning & Maintenance section for regular maintenance of the appliance.
43 To disconnect, press the power button to turn the unit off, then unplug from socket when not in use and
before cleaning.
44 DO NOT clean this product with a water spray or the like.
45 DO NOT clean with metal scouring pads. Pieces can break off the pad and touch electrical parts, creating
a risk of electric shock.
46 Store indoors when not in use - out of reach of children.
47 DO NOT keep uncovered grill exposed to elements. ALWAYS use grill cover when stored outdoors.
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE • FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS.
PARTS & ACCESSORIES
To order replacement or additional parts and accessories,
visit ninjakitchen.com.au or ninjakitchen.co.nz
A Grill Plate
B Crisper Basket
C Smoke Box (pre-installed)
D Grease Tray
E Left and Right
Assembly Handles
F Socket Head Cap Screw
3.5mm x 16mm (4x)
(pre-assembled on handles)
G Allen Key
H Pellet Scoop
I Assembled Main Unit
(power cord not shown)
J Lid
K Control Panel
L Onboard Probe Storage
M Ninja Smart Probe
N ON/OFF Press
A
C
E
F
G
H
I
J
K
B
D
1 Remove and discard any packaging material and tape from the unit. Some stickers are to be permanently
kept on the unit, ONLY remove stickers with ‘peel here’.
2 Remove all accessories from the package and read this manual carefully. Please pay particular attention to
operational instructions, warnings and important safeguards to avoid any injury or property damage.
3 Wash the grill plate and crisper basket in warm, soapy water, then rinse and dry thoroughly. The grill plate,
crisper basket and base unit are NOT dishwasher safe. NEVER clean the main unit in the dishwasher.
NOTE: The base liner underneath the bottom heating element may have some visible discoloration.
This is a result of our normal manufacturing process. The unit has not been previously used.
4 DO NOT use abrasive brushes or sponges on the cooking surfaces, as they will cause damage to the coating.
5 Plug into electrical socket and press the switch located underneath the left side of the control panel to the
ON position. (See Fig. A above).
6 To turn your product o, ensure the dial is rotated to the OFF position and the press switch is OFF.
BEFORE FIRST USE
We recommend placing all accessories inside the grill and running it on GRILL, temp set to HI for 20 minutes without
adding food. This removes any residues. This is completely safe and not detrimental to the performance of the grill.
L
M
N (Fig. A)
3
AUS +61 2 8801 7666 | NZ +64 800 112 660
4
ninjakitchen.com.au | ninjakitchen.co.nz
GETTING TO KNOW THE WOODFIRE ELECTRIC BBQ GRILL & SMOKER
HANDLE INSTALLATION
1 Ensure the correct handle is being used on the
left and right side. (Refer to Fig. A and note
that the handles have L and R stickers on the
underside). A Allen Key is taped onto the left
handle (see Fig. A).
2 Place unit at edge of table (Fig. B) OR with lid
still taped down, carefully place grill upside
down by holding the sides of the unit and the
lid down. If tape has been removed, remove all
accessories from the grill and holding the sides
of the unit and the lid down, place grill on top
of top pulp tray piece to protect unit (Fig. C).
3 Align each handle with tabs on base, then push
up to set each handle in place (Fig. D). Use
included Allen Key to tighten pre-assembled
screws (2x) on each handle (Fig. E).
POWERING THE GRILL
1 Plug the RCD into electrical socket. Switch
socket on.
2 Press RESET button on the RCD. The circle above
the RESET button should be illuminated orange. If
this isn't the case, try a dierent socket.
3 Press the TEST button on the RCD. The circle
should now show black. This means the RCD
is functioning correctly. If pressing the TEST
button does not change the circle to black then
contact customer services.
4 After establishing if the RCD is functioning
correctly once again press RESET. The orange
illumination should re-appear. The unit can now
be switched on.
5 Press the on/o switch on the back of the
control panel. Switch is on when the side with
the line is pressed down.
6 Now turn the dial on the front of the control
panel and turn it to the desired function. The
display should illuminate to reveal times or
temps. The grill is now ready to use.
EXTENSION CORD
1 If using an extension cord, ensure it is
suitable for use outdoors with outdoor
appliances. Using the incorrect cord could
lead to the cord overheating, melting and/
or a drop in voltage. A drop in voltage can
increase preheat times and impact cooking
performance and/or cook times.
BEFORE FIRST USE - CONTINUED
Fig. A
Fig. B
Fig. C
Fig. D
Fig. E
FUNCTION BUTTONS
There are 2 ways to achieve authentic smokey
BBQ flavours:
1. Dedicated SMOKER program for cooking
over a longer period of time for deep flavours
and tender results.
2. Add a quick burst of Woodfire Flavour to any
of the other functions using the WOODFIRE
FLAVOUR TECHNOLOGY button.
GRILL: Closed-lid cooking for top and bottom
heat. Best when grilling large or thick cuts of
meat or frozen food or for an all-around sear.
Open the lid while grilling delicate foods or lean
proteins to develop chargrilled textures without
overcooking.
WOODFIRE FLAVOUR TECHNOLOGY: Press
after selecting your cooking function to add
Woodfire Flavour using the Grill, Air Fry, Bake,
Roast or Dehydrate functions. When pressed,
flame icon will illuminate on the display screen.
SMOKER: Create deep, smoky flavours while
cooking low and slow to tenderise large cuts
of meat.
AIR FRY: Achieve crispiness and crunch with
little to no oil and higher fan speeds.
ROAST: Tenderise meats, roast vegetables and
more.
BAKE: Bake breads, cakes and more with lower
fan speeds.
DEHYDRATE: Great for drying fruits, vegetables
and jerky.
REHEAT: Ideal for reheating leftovers so
nothing goes to waste.
OPERATING BUTTONS
DIAL: To power on the unit and select a cooking
function, rotate the dial clockwise until desired
function is selected. To power o the unit, rotate
the dial anti-clockwise to the OFF position.
NOTE: When the unit is powered on, the
display will be illuminated.
/ TEMP: Use the and buttons
to the left of the display screen to adjust
the cook temperature.
/ TIME: Use the and buttons to the right
of the display screen to adjust the cook time.
START/STOP: Press to start or stop the current
cook function or press and hold for 3 seconds to
skip preheat.
MANUAL: Switches the display screen so you can
manually set the target temperature for the probe.
PRESET: Switches the display screen so you can
select a preset target temperature for the probe
based on food load and desired results.
PREHEAT FOR BETTER RESULTS
For best grilling results, let the unit fully preheat
before adding food. Adding food before
preheating is complete may lead to overcooking,
smoke and longer preheat time.
After you set function, time and temperature
then press START, the unit will automatically
begin preheating (except if using the Smoker
function or the Reheat/Dehydrate functions)
without enabling Woodfire Flavour technology.
NOTE: RCD Light; ORANGE = RCD is ON;
BLACK = RCD is OFF.
NOTE:
It may be dicult to see the orange if in
direct sunlight.
NOTE:
The RESET button on the RCD will need
to be pressed every time the unit is unplugged or
the socket switched o.
Termékspecifikációk
| Márka: | Ninja |
| Kategória: | Barbecue |
| Modell: | OG751ANZ |
Szüksége van segítségre?
Ha segítségre van szüksége Ninja OG751ANZ, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók Barbecue Ninja
29 Augusztus 2024
Útmutatók Barbecue
- Barbecue Rommelsbacher
- Barbecue Weber
- Barbecue Alpina
- Barbecue Maxxus
- Barbecue Shuttle
- Barbecue Lagrange
- Barbecue Severin
- Barbecue Mirpol
- Barbecue Campart Travel
- Barbecue Redmond
- Barbecue Commercial Chef
- Barbecue DCS
- Barbecue Proline
- Barbecue Tenneker
- Barbecue Livoo
Legújabb útmutatók Barbecue
10 Április 2025
9 Április 2025
6 Április 2025
2 Április 2025
2 Április 2025
2 Április 2025
31 Március 2025
30 Március 2025
28 Március 2025
16 Január 2025
