USER GUIDE
PLCAPE50
5.0 Farad Digital Power Capacitor
www.PyleUSA.com
2
www.PyleUSA.com
3
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Introduction
This manual provides detailed information on the function, installation, and
operation of the power capacitor.
To avoid possible injury and damage to your audio system, please study the
manual carefully before you start the power capacitor installation.
Operation
The digital display capacitor is an energy storage device designed to
supplement the audio amplier's power supply during high current demand.
An example of such a demand is when music hits a low bass transient.
The overall bass response of an audio system will be enhanced by using this
device. It is capable of storing a large amount of energy which can be
discharged very quickly when needed.
This makes the power capacitor a logical addition to the audio system, as
automotive batteries are not designed to deliver the current required in
high-power car audio installations.
Another feature of the digital display capacitor is its ability to lter car AC
voltage induced by the amplier's power supply. This can otherwise cause
audible noise in the car's sound system.
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING
THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
WARNING:
• This power capacitor may explode and cause serious injury or death if
abused or connected improperly.
• Refer to the installation manual for correct procedures when making
connections, and/or charging/discharging the capacitor.
• Do not expose the capacitor to voltages higher than specied at any time.
• Do not install in direct sunlight or extreme temperatures.
CAUTION:
Improper connection of this product can cause electrical damage to the
vehicle and/or equipment. PyleUSA assumes no responsibility for any
damages that could occur due to improper connection of this product.
TABLE OF CONTENTS
Introduction
Operation
Installation
Power-Up Procedures and Display Function
Features and Technical Specs
Register Product
3
3
4
6
7
7
www.PyleUSA.com
4
www.PyleUSA.com
5
Installation
For maximum performance, the digital power capacitor should be installed as
close to your amplier as possible. The ideal location is one that allows short
wiring runs while keeping the capacitor somewhat isolated from the heat
created by the amplier system. The positive power wire should be kept as
short as possible and should be connected to the amplier's battery supply
cable. We recommend that a high-performance distribution block be used to
create a splice into this cable (as shown below).
No fuses should be installed in the wire between the power capacitor and the
amplier system, but make sure there is an appropriate fuse at the battery in
the main supply cable. The ground cable for the power capacitor should be
kept as short as possible and should be connected directly to the vehicle's
chassis at a bare metal surface. Do not ground the capacitor directly to the
amplier ground terminal or ground cable (see Fig. 1).
The positive and negative wires to the capacitor should have the same gauge
as the amplier power wires. High-performance 8 or 10 AWG OFC power
cables are a good choice for this application.
If the digital display has a remote terminal, remember to connect it with the
remote terminal of your amplier(s) using 18 to 20 AWG primary wire (see Fig. 2).
REM (ON/OFF) = REMOTE CONTROL
Connect the REM terminal to the automatic antenna connector of your car
radio. Now, when turning on and o your car radio, the amplier automatically
switches on and o. A cable diameter of 0.5 mm² is sucient.
g. 1
g. 2
