AW70V6
70V Surface Mount Indoor/Outdoor Speakers
Installation Manual
2Russound AW70V6 70V Surface Mount Indoor/Outdoor Speaker Installation Manual
Speaker assembly
The bracket has screw slots to accommodate either wall,
ceiling and pole-mounted installation options. A "C-slot"
bracket design allows for one-handed installation by allowing
the bracket to support the speaker's weight until it is locked
into position. Custom, easy-to-turn, weather-resistant knobs
provide a versatile and cosmetic nish for the brackets'
attachment points.
SPEAKER ASSEMBLY INTRODUCTION
Introduction
Thank you for selecting the AW70V6 speakers from Russound.
The AW70V6 speakers are designed to add high quality,
custom-tailored sound for distributed audio systems using
either 70V or 100V amplication. With an easily adjustable
weatherproof tap setting switch on the rear panel, these
versatile speakers even include a bypass setting to allow their
use as high performance 6-ohm speakers. Their 1 titanium
dome tweeters combined in a ported-cabinet design with 6.5”
injection-molded polypropylene woofers, provide the audio
quality that our customers have come to know and expect
from Russound, while rugged enough for even the most
extreme outdoor environments.
Bracket
Mounting Knob
Speaker
Mounting Screws
(Not included)
Russound AW70V6 70V Surface Mount Indoor/Outdoor Speaker Installation Manual 3
SPEAKER BACK PANEL
1/4"- 20 Brass Inserts - ts many aftermarket mounting
systems if desired. Follow directions included with the
aftermarket product.
Tap Setting Knob - for easy adjustment of the tap settings
with options for:
7.5W, 15W, 30W, 60W (70V)
15W, 30W, 60W (100V)
Bypass
Binding Posts - to secure speaker wire, up to 12 gauge.
