IC-605
Magnetic square grille
ICG-6S (sold separately)
Drill Pilot Hole
Mark Template
Outline
Test for
stud
clearance
Score
template
outline
Cut out
opening
Note:
Drill shallow to avoid damage to
wiring, pipes & ductwork.
For warranty information go to
www.russound.com/warranty-registration
speaker wire to the speaker location avoiding
all obstacles.
Russound offers Speaker Rough-In Brackets
bracket for speaker wire tie-off to keep the wire
from being lost during construction.
Make sure the speaker cut-out (hole) doesn't
of the mounting bracket.
for In-ceiling bracket installation.
wiring before cutting any holes in the ceiling.
for In-wall bracket installation
1. Center the cardboard template between
opening.
2. Score the outline of the template with a
utility knife to prevent chipping. If dealing
the pencil outline. Use a fine-toothed
keyhole saw or hacksaw blade with slow
strokes to saw through and remove the
inner surface.
3. Center the Speaker in the the cutout.
Rotate the frame as needed before
not overtighten.
Attach the speaker wires to the red and black
speaker terminals. Connect the Positive (+)
conductor to the Red terminal and the Negative
(-) conductor to the Black terminal. Make sure
that no stray strands of wire are touching the
other conductor or terminal.
10.15.20 | Rev 1
The All New Speakers from RussoundArchitectural
The innovative IC-Series of Speakers from Russound incorporates the latest advances in material Architectural
technologies and audio engineering to provide the best sounding speaker lineup in Russound’s 50-year history. Each
of these new speakers has been designed, manufactured and tuned with great care so that your listening experience
is truly exceptional. Our range of speaker solutions provide excellent choices in any application - from background
music listening to premium performance in your favorite listening areas at home.
While designed for premium sound quality, Russound also included features that will make
these easier to install, saving time and money for all involved. For that, Russound included
its unique Easygrip™ tweeter posts and bridges to make all of the IC-Series speakers easy to
hold at the top of a ladder, and most importantly, for its premium models, the IC-620,
IC-620T, IC-820T, IC-630 8 and IW-630IC-820, and IC- 30, as well as the in-wall IW-620 ,
Russound incorporated its proprietary, patented SwiftLock technology for effortless ®
installation at the push of a button.
The IC-Series of speakers provides excellent options for all of the speakers in the home, from
complete multi-room audio solutions to dedicated home theaters and everything in between .
From the kitchen to the living room to the bedroom, there is a perfect speaker for every room.
Engineered Innovation
Extraordinary Sound
IC-Series Loudspeakers
IC-60 5
Contractor Grade Loudspeakers
Two-way In-ceiling / 4-Pack
IC-610T
Stereo Sound From A Single Speaker
Single Point Stereo In-ceiling
IC-6 0 2 T
Designed for Primary Listening Areas
Single Point Stereo In-ceiling
•
Designed for small rooms, hallways, or anywhere
that stereo speaker installation is difficult
•
Dual Tweeter and Dual Voice-Coil Woofer
•
Enhanced frequency response for superb sound
•
Swift oc installation L k® tool-less quick and easy
IC-610
Perfect For All Background Music Applications
Two-way In-ceiling
•
Quick and easy
•
Tool-less Installatio n
•
Available on all 20 &
30 Series Loudspeakers
•
Install at the p ush of a
button
•
US
Patent 1 0,024,493
©2020
Russound.
All rights reserved. All tradem respec Specifiarks are property of their tive owners. cations are subject to
change without notice. Russound is not responsible for typographical errors or omissions. The Bluetooth
® word mark and
logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Russound is under license.
Other trademarks and trade names are those of artheir respective owners. AirPlay, iPad, iPhone, and iPod touch e
trademarks of Apple lnc., reg istered in t Uhe .S. and other countries.
1 Forbes Road I Newmarket, NH 03827
800.638.8055
w ww.russound.com
IW-620
Designed for Primary Listening Areas
Two-way In-wall
•
Integrated one-piece baffle /woofer basket design for
enhanced rigidity and more efficient bass
•
Acoustically matched with the IC-620 , IC-620T, I , C-820
and IC-820T - mix and match in a home as needed
•
Swift ock installation L ® tool-less quick and easy
Optional Square
Grilles available for
in-ceiling peakerss
(not included)
Optional Rough-in-
Brackets for
in-ceiling speakers
(not included)
•
Designed for background listening applications
•
Pin-Cushion, EasyGripTM Design for easily holding the
speaker with one hand even at the top of a ladder
•
Integrated one-piece baffle /woofer basket design for
enhanced rigidity and more efficient bass
•
Your new go-to speaker for distributed audio systems
•
Pin-Cushion, EasyGripTM Design for easily holding the
speaker with one hand even at the top of a ladder
•
Integrated one-piece baffle /woofer basket design for
enhanced rigidity and more efficient bass
•
Designed for small rooms, hallways, or anywhere that
stereo speaker installation is difficult
•
Dual Tweeter and Dual Voice-Coil Woofer
•
Pin-Cushion, EasyGripTM Design for easily holding the
speaker with one hand even at the top of a ladder
•
Use instead of the IC-620 for larger rooms, rooms with
higher ceilings, or for deeper bass response
•
Acoustically matched with the IC-620 - mix and match
in a home as needed
•
SwiftLock® tool-less quick and easy installation
IC-620
Designed for Primar y Listening
Areas Two-way In-ceiling
IC- 0 82 T
D esigned for Primary Listening Areas
Single Point Stereo In-ceiling
•
Use instead of the IC-620 for larger rooms, rooms with
higher ceilings, or for deeper bass response
•
Acoustically matched with the IC-620, IC-620T, IC-820T &
IW-620 - mix and match in a home as needed
•
SwiftLock® tool-less quick and easy installation
IC- 208
Designed for Primar y Listening Areas
Two-way In-ceiling
•
Designed for anywhere that stereo speaker
installation is difficult
•
Dual Voice-Coil Tweeter and Dual Woofer
•
Enhanced frequency response for superb sound
•
Swift oc installation L k® tool-less quick and easy
IC-630
Ideal For Critical Listening Areas & Home Theaters
Two-way In-ceiling
•
Enhanced frequency response for superb sound
•
Excellent for both music and TV/movie/home theater
use
•
Swift oc L k® tool-less quick and easy installation
IC- 0 83
Ideal For Critical Listening Areas & Home Theaters
Two-way In-ceiling
•
Use instead of the IC-630 for larger rooms, rooms
with higher ceilings, or for deeper bass response
•
Acoustically matched with the IC-630 & IW-630 - mix
and match in a home as needed
•
Swift oc installation L k® tool-less quick and easy
IW-6 0 3
Ideal For Critical Listening Areas & Home Theaters
Two-way In-wall
•
Integrated one-piece baffle /woofer basket design for
enhanced rigidity and more efficient bass
•
Acoustically matched with the IC-6 03 and IC-8 03 - mix
and match in a home as needed
•
