998000716
11-21-24 (REV:03)
FIRST TIME ASSEMBLY STARTING THE UNIT
USING DETERGENT
NOZZLE SELECTION GUIDE
Use of soap nozzle will activate soap injector at a 20:1 dilution ratio.
WARNING! Never use bleach or solvent-based detergent.
• Will damage your pump
• Will void your warranty
• Will damage plants/shrubs
BEFORE STORING THE UNIT
Always add Pump Protector to the unit after each use and before storing. This will significantly
improve pump life (see page 13).
Pump protector is available from your local retailer. For further assistance, call customer
service at 1-800-525-2579.
To add, follow the instructions provided by the Pump Protector manufacturer.
1
Make the most of your purchase! Go to www.ryobitools.com
and register your new tool online. For questions about operating or
maintaining your product please call, 1-800-525-2579.
Completely uncoil garden hose or remove
completely from reel to prevent kinks.
Turn water faucet on fully.
Make sure there are no leaks.
With no nozzle installed, squeeze the trig-
ger to relieve air pressure. Hold the trigger
until a steady stream of water appears.
RY143011 QUICK REFERENCE GUIDE
There may be residual water in the
pump due to performance testing.
WARNING:
This Quick Reference Guide is not a substitute for reading the operator’s manual. To reduce the risk of injury or death, user must read and understand operator’s manual
before using this product. All page references refer to the operator’s manual.
Install the wheels (see page 8).
1
Unfold the handle assembly (see page 8).
2
Connect the high pressure hose to the
trigger handle (see page 8).
Connect your garden hose to the pressure
washer (see page 9).
4
5
Connect the spray wand to the trigger
handle (see page 8).
3
Connect the pressure washer to the power supply. Press the reset button on the plug to make sure
the unit is ready for operation (see page 10).
1
This pressure washer is not recommended for use with an extension cord. If using an extension cord,
arrange a drip loop to avoid the possibility of the tool plug getting wet (see pages 2, 6 and 7).
2
When finished, press switch OFF to stop the motor (see page 10).
3
Press switch ON to start the motor (see page 10).
Install nozzle and rotate selector
to blue
or blue setting
(see page 12).
21
Pour pressure washer detergent
in soap tank (see page 12).
3
Squeeze trigger and wait approx.
5 seconds for detergent
(see page 12).
USE ONLY THIS SIZE EXTENSION CORD WHEN USING
THIS PRODUCT:
Cord Length Wire Size (A.W.G.)
25 ft. 12
50 ft. Not Allowed
NOTE: A.W.G. = American Wire Gauge
Connect the high pressure hose to the
pump (see page 9).
6
Use the chart below to determine the correct nozzle for your job.
SWITCH
ON
SWITCH
OFF
HIGH PRESSURE
(NO SOAP WHEN USING THESE NOZZLES)
LOW
PRESSURE
(FOR SOAP OR
GENTLE RINSE)
Turbo
Nozzle
15º
25º
40º
Long
Range
Short
Range
Concrete, Brick, Masonry
Siding, Gutters, House
Fencing, Deck, Patio
Lawn Equipment, Boat, RV
Recommended Nozzle
Use With Caution for Certain Applications
5 S
PUMP
PROTECTOR
