Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 12, 2023 9:23 AM

Product ID

145B-USBC-HDMI4K-AOC

146B-USBC-HDMI4K-AOC

ComponentFunction

1USB-C Connector

• Connect to a USB-C Source Device

• USB-C Source Device must support DP Alt

Mode

2HDMI ConnectorConnect to an • HDMI Display

3USB Power Cable

• Connect to an availableor USB Port USB Wall

Charger

USB-C to HDMI 2.0b Optical Adapter Cable - HDR - 4K 60Hz

Product Information

For the latest technical specications and declarations of conformance, please visit:

www.StarTech.com/145B-USBC-HDMI4K-AOC

www.StarTech.com/146B-USBC-HDMI4K-AOC

Requirements

• USB-C DP Alt Mode Source Device x 1

• HDMI Display Device x 1

• USB Port or USB Wall Charger x 1

Package Contents

• USB-C to HDMI Cable x 1

• Quick-Start Guide x 1

Installation

Installing the USB-C to HDMI Cable

1. Connect the of the to an available on the HDMI ConnectorCable HDMI Input Port

Display.

2. Connect the attached , located on the of the , to USB Power CableHDMI End Cable

an available or .USB PortUSB Wall Charger

3. Connect the of the to an available on the USB-C ConnectorCable USB-C PortHost

Device.

Note: The Host Device’s USB-C Port must support DP Alt Mode.

12

3
