Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: April 18, 2024

Product ID

1P3FFCB-USB-SERIAL

1P6FFC-USB-SERIAL

1P10FFC-USB-SERIAL

ComponentFunction

1Serial Port DB9• Connect to a Serial Peripheral Device

2DB9 Screws

• Used to secure the to the Serial DB9 Port Serial

Peripheral Device

• The included can be installed for DB9 Nuts

compatibility with or Serial Peripheral DevicesCables

3LED Indicators

• Data Receive LED: Green Flashes to indicate activity

• Data Transmit LED: Yellow Flashesto indicate activity

• USB LED: BlueSolid to indicate driver has been

installed, and USB connection enumerated

4USB Type A Port

• Connect the to an available USB to Serial Adapter

USB-A Port

Pinout Diagram

FTDI USB-A to RS232 DB9 Serial Adapter Cable - M/M - ESD Level 4

Package Contents

• USB to Serial Adapter x 1

• DB9 Nuts x 2

• Quick-Start Guide x 1

Requirements

• USB Type-A Enabled Computer x 1

For the latest drivers/software, product information, technical specications, and

declarations of conformance, please visit:

www.StarTech.com/1P3FFCB-USB-SERIAL

www.StarTech.com/1P6FFC-USB-SERIAL

www.StarTech.com/1P10FFC-USB-SERIAL

Installation

Install the Driver and Adapter

Note: Drivers should install automatically in most supported operating systems. If

they do not, please complete the following steps:

1. Navigate to:

b. www.StarTech.com/1P3FFCB-USB-SERIAL

c. www.StarTech.com/1P6FFC-USB-SERIAL

d. www.StarTech.com/1P10FFC-USB-SERIAL

5. Click the tab.Drivers/Downloads

6. Under , download the appropriate for your operating Driver(s)DriverPackage

system.

Windows

1. Right-click the downloaded le and extract the contents with .Extract All

2. Browse the Windows folder and run the le.Setup

3. Follow the on-screen instructions to complete the installation.

4. Connect the to an available USB-A port.USB to Serial Adapter

macOS

1. Double-click the downloaded le.

2. Open the folder that matches your and run the le inside macOS VersionInstaller

the folder.

3. Follow the on-screen instructions to complete the installation.

4. Connect the to an available USB-A port.USB to Serial Adapter

43

1

PinRS-232

1DCD

2RXD

3TXD

4DTR

5GND

6DSR

7RTS

8CTS

9RI

2

2

54321

9876
