Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: May 25, 2020 4:41 PM

Product Diagram (RJ45SPLITTER)

ComponentFunction

1RJ45 Connector

• Connect the to an existing Cable Adapter

Network.

2RJ45 Ports

• Allows you to connect up to 2 Network Devices

to an existing .Network

Requirements

For the latest requirements, please visit www.startech.com/RJ45SPLITTER

• Network Devices x 2 (max 2)

• CAT5 Cables x 2

• Existing Network

Installing the Cable Adapter

1. Connect the on the to an RJ45 port on a RJ45 ConnectorCable AdapterNetwork

Device (Ethernet Patch Panel, Wall Outlet, etc.).

Note: The on the combines the signals of 2 connections CAT5 CableCable Adapter

over the one .CAT5 Cable

2. Connect a to the on the and the other side to an CAT5 CableRJ45 PortCable Adapter

RJ45 port on a .Network Device

3. Repeat step 2 to connect a second to the .Network DeviceCable Adapter

2-to-1 RJ45 Splitter Cable Adapter - F/M

Connectivity Diagram

The lays out the following scenario:Connectivity Diagram

Scenario: A company has two oces (A and B). A single CAT5 Ethernet drop connects

Oce B to the network. The company wants to put a network printer and wireless

access point in Oce B. They would like to have a dedicated Ethernet connection for

each device back to the Network Switch in Oce A.

Solution:Cable Adapters By using the two one at each location, the company can

combine two connections to the switch over the existing wiring at Oce A and split

the signal back into two connections at Oce B.

1

2
