Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Product Diagram (ST8CU824)

ComponentsFunction

1Short-Circuit LEDs (8)

• Indicates that the correspondingSolid Red:

USB-A Port has shorted, and that the port has

been deactivated, to protect the connected

device.

• The port will remain deactivated until the

Charging Station is power-cycled.

2Power Button• Used to turn the On or O.Charging Hub

3DC IN 12V• Used to power the .Charging Hub

4USB-A Ports (8)

• Used to charge multiple (max = 8).Devices

• Voltage at the common collector (VCC) = 5V

• Ground (GND) = 5V

• D+ = 2.7V

• D- = 2.0V

8-Port Charging Station for USB Devices | 8x 2.4A

2

Requirements

For the latest requirements, please visit www.startech.com/ST8CU824

• Phillips Head Screwdriver (Optional)

Installation

Notes: The features a chipset that can detect the required charging Charging Hub

mode of a device, and switch to the proper mode for full-speed charging (e.g. If an

Apple device is connected, it will automatically charge to Apple charging mode

specications).

When charging multiple devices, the may become warm to the touch, Charging Hub

this is normal and will not harm the connected .Device(s)

1. Connect the to an and the other end to the Power AdapterAC Electrical Outlet DC

IN 12V Port Charging Hub on the.

2. Press the to turn the On. Power ButtonCharging Hub

3. Connect your to the corresponding on the .Device(s)USB-A PortsCharging Hub

Installing the Mounting Brackets (Optional)

Note: Before installing the to the mounting surface, contact a Mounting Bracket

professional. Product mounting should be completed by a certied professional as per

the local safety and building code guidelines.

1. Align the on the with the four Mounting HolesMounting BracketMounting Holes

on the back of the .Charging Hub

2. Insert the (x4) through the and into the Bracket ScrewsMounting Bracket

Mounting Holes Charging Hubon the back of the.

3. Tighten the using a , be careful not to Mounting ScrewsPhillips Head Screwdriver

over-tighten.

Installing the Rubber Feet (Optional)

1. Remove the from the .Rubber FeetAdhesive Strip

2. Align each of the on the back of the close to each of Rubber FeetCharging Hub,

the four corners.

3. Remove the adhesive backing and apply the to the .Rubber FeetCharging Hub

Note: Be careful not to cover the when applying the .Mounting HolesRubberFeet

3

1

4

Manual Revision: May 4, 2022 4:11 PM
