SWIFT RIO

TECHNICAL HANDBOOK

1414362

SWIFT GROUP

Dunswell Road

Cottingham

East Yorkshire HU16 4JX

Tel 01482 875740

Fax 01482 840082

email enquiry@swiftgroup.co.uk

For more information visit

www.swiftgroup.co.uk

Issued July 2015

BROCHURE

DOWNLOADS

FIND A

DEALER

FACEBOOK AND

SWIFT-TALK.CO.UK

PRODUCT VIDEOS

SWIFTTV.CO.UK

FIND OUT MORE SWIFTGROUP.CO.UK

Contents

Speciﬁcations 2 .............................................................................

Capacities 5 ...................................................................................

Towing Capabilities 6 ....................................................................

Jacking 8 .......................................................................................

Wiring Diagrams 9 .........................................................................

Bulb Chart 15 .................................................................................

Bulb Replacement 16 ......................................................................

2 3

Speciﬁcations

NOTE: 1. The Maximum User Payload includes:

a) the conventional load (this is the allowance for

passengers)

b) essential habitation equipment (items and

ﬂuids required for safe and proper functioning of

habitation equipment)

c) optional equipment (items available from

the manufacturer over and above the standard

speciﬁcation)

d) personal effects (those items not covered by

the above)

2. The is the mass of the Mass in Running Order

unladen vehicle including a 75kg allowance for the

driver plus engine coolants and 90% of the fuel tank

and 1 x 6kg Calor Lite gas cylinder.

The MRO is calculated with the fresh water tank

empty. If you travel with water in the fresh water tank

then the payload will reduce accordingly.

3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE

ALLOWED FOR THE MASSES OF ALL ITEMS YOU

INTEND TO CARRY IN THE MOTOR CARAVAN,

e.g. passengers, optional equipment, essential

habitation equipment and personal effects, such

as clothing, food, pets, bicycles, sailboards, sports

equipment etc.

4. - UNDER NO CIRCUMSTANCES WARNING

SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE

LADEN MASS OF THIS MOTOR CARAVAN BE

EXCEEDED.

Model

Rio 310

Standard

Rio 310

Optional

Rio 320

Standard

Rio 320

Optional

Rio 325

Standard

Rio 325

Optional

Roof Proﬁle

Low Line Low Line Low Line Low Line Low Line Low Line

Engine

130 MJT 130 MJT AUTO 130 MJT 130 MJT AUTO 130 MJT 130 MJT AUTO

Engine Capacity

2287cc 2287cc 2287cc 2287cc 2287cc 2287cc

Max Power

96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm

Torque

320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm

Chassis

MLWB Fiat Low Line Chassis MLWB Fiat Low Line Chassis LWB Fiat Low Line Chassis LWB Fiat Low Line Chassis MLWB Fiat Low Line Chassis MLWB Fiat Low Line Chassis

Wheel base

3.80m/12'6" 3.80m/12'6" 4.04m/13'3" 4.04m/13'3" 3.80m/12'6" 3.80m/12'6"

Designated Passenger Seats excluding Driver

1 1 3

Berths (sleeping positions)

2 2 2

Overall Length (no ladder)

5.99m/19'8" 6.40m/20'12" 5.99m/19'8"

Overall Width (mirrors folded)

2.26m/7'5" 2.26m/7'5" 2.26m/7'5"

Overall Height

2.78m/9'1" 2.78m/9'1" 2.78m/9'1"
