1414576

SWIFT GROUP

Dunswell Road

Cottingham

East Yorkshire HU16 4JX

Tel 01482 875740

Fax 01482 840082

email enquiry@swiftgroup.co.uk

For more information visit

www.swiftgroup.co.uk

Issued July 2015

BESSACARR

TECHNICAL HANDBOOK

BROCHURE

DOWNLOADS

FIND A

DEALER

FACEBOOK AND

SWIFT-TALK.CO.UK

PRODUCT VIDEOS

SWIFTTV.CO.UK

FIND OUT MORE SWIFTGROUP.CO.UK

Swift reserves the right to alter speciﬁcations and prices at any time as materials

and conditions demand. Please check the website for the latest updates.

Contents

Speciﬁcations 2 .............................................................................

Capacities 9 ...................................................................................

Towing Capabilities 10 ..................................................................

Jacking 12 .....................................................................................

Wiring Diagrams 13 .......................................................................

Bulb Chart 19 .................................................................................

Bulb Replacement 20 ......................................................................

2 3

Speciﬁcations

NOTE: 1. The Maximum User Payload includes:

a) the conventional load (this is the allowance for

passengers)

b) essential habitation equipment (items and

ﬂuids required for safe and proper functioning of

habitation equipment)

c) optional equipment (items available from

the manufacturer over and above the standard

speciﬁcation)

d) personal effects (those items not covered by

the above)

2. The Mass in Running Order is the mass of the

unladen vehicle including a 75kg allowance for the

driver plus engine coolants, 90% of the fuel tank and

1 x 6kg Calor Lite cylinder.

The MRO is calculated with the fresh water tank

empty. If you travel with water in the fresh water tank

then the payload will reduce accordingly.

3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE

ALLOWED FOR THE MASSES OF ALL ITEMS YOU

INTEND TO CARRY IN THE MOTOR CARAVAN,

e.g. passengers, optional equipment, essential

habitation equipment and personal effects, such

as clothing, food, pets, bicycles, sailboards, sports

equipment etc.

4. WARNING - UNDER NO CIRCUMSTANCES

SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE

LADEN MASS OF THIS MOTOR CARAVAN BE

EXCEEDED.

* Estimated

** For optional roof ladder add 125mm to length and

40mm to Low Line height.

Model

Bessacarr 412

Standard

Bessacarr 412

Optional

Bessacarr 424

Standard

Bessacarr 424

Optional

Bessacarr 462

Standard

Bessacarr 462

Optional

Roof Proﬁle

Low Line Low Line High Line High Line High Line High Line

Engine

130 MJT 130 MJT 130 MJT130 MJT AUTO 130 MJT AUTO 130 MJT AUTO

Engine Capacity

2287cc 2287cc 2287cc 2287cc 2287cc 2287cc

Max Power

96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm

Torque

320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm 320 @ 1800rpm

Chassis

SWB Fiat Low Line Chassis SWB Fiat Low Line Chassis MLWB Fiat Low Line Chassis MLWB Fiat Low Line Chassis MWB Fiat Low Line Chassis MWB Fiat Low Line Chassis

Wheel base

3.00m/9'10" 3.80m/12'6" 3.45m/11'4"

Designated Passenger Seats excluding Driver

1 3 1

Berths (sleeping positions)

2 4 2

Overall Length (no ladder)**

5.98m/19'7" 5.99m/19'8"* 6.53m/21'5"*

Overall Width (mirrors folded)

2.38m/7'10" 2.38m/7'10" 2.38m/7'10"

Overall Height**

2.82m/9'3" 2.82m/9'3" 2.82m/9'3"
