Oldal 1/8
Features
Applications
Specifications
www.VikingElectronics.com
• Automatic polling and programming software included
• 2 Amp relay contacts for door/gate or SL-2 strobe light control
• SIP compliant (see page 2 for more information)
• Outbound Proxy, Authentication ID, Peer to Peer, VLAN Tagging
• PoE powered (class 1, <4 Watts)
• Automatic Noise Canceling (ANC) feature for proper operation in noisy areas
• VoIP eliminates the need for “Push to Talk” mode
• Network downloadable firmware
• Meets ADA requirements for Emergency Phones:
- Automatically lights the Red “Call Connected” LED
- Transmits a unique location I.D. code or voice announcement
- Grade 2 Braille label for the visually impaired
• Non-volatile digital voice announcer with 28 seconds of voice memory
• Handsfree operation
• Marine grade 316 stainless steel prevents corrosion on the stainless steel models
• Laser etched graphics on stainless steel models
• Dials up to 5 emergency numbers
• E-1600-20-IP, E-1600-22-IP, E-1600-52-IP, and E-1600-TP2IPEWP dial up to 5
non-emergency “INFO” numbers
• Cycles through backup phone numbers on busy or no-answer
• Optional Enhanced Weather Protection (EWP), EWP products are designed to meet
IP66 Ingress Protection Rating, see DOD 859
• Hangs up on busy signal, time-out or touch tone command
• Extended temperature range (-40°F to 140°F)
• 11 different chassis or board only available
• Available in 42” tower phone model E-1600-BLTIPEWP (DOD 249)
• Optional LV-1K Line verification Panel (DOD 246 )
• Optional PB-100 Polling System available (DOD 232)
• Optional SL-2 or BLK-4-EWP strobe light kit available (DOD 242/654)
• Optional E-1600A-MK-GNP Pedestal Mounting Kit (DOD 227)
• Optional PB-1 Panic Button Kit (DOD 233)
• Diagnostics for testing microphone, speaker, and relay
Power: PoE class 1 (<4 Watts)
Maximum Sound Pressure: 95 dB SPL @ 1m
Dimensions: See Installation and Specifications
Operating Temperature: -40°F to 140°F (-40° C to 60° C)
Humidity - Standard Products: 5% to 95% non-condensing
Humidity - EWP Products: Up to 100%
Audio Codecs: G711u, G711a, G722
Network Compliance: IEEE 802.3 af PoE, SIP 2.0 RFC3261, 100BASE-TX with
auto cross over
Regulatory Compliance: CE, FCC Part 15 and Canada ICES-003 Class A
Connections: (1) RJ45 10/100 Base-T, (3) gel-filled butt connectors
* Americans with Disabilities Act of 1992 contains federal
regulations regarding elevator telephones (Public Law 101-336).
• Elevators
• Parking ramps/lots
• Emergency pool phones
• ATM machines
• Medical centers
• Silent hold-up alarm dialer
with an optional PB-1 Panic
Button Kit (DOD 233)
• Area of refuge locations
• Lobbies
• Entryways
• Campus emergency stations
• Stadiums
• Convention centers
• Public access areas
ADA & CE Compliant VoIP Emergency Phones
with Built-In Dialer and Digital Voice Announcer
The 1600-IP Series of ADA Compliant VoIP Emergency Phones are designed to
provide quick and reliable handsfree communication for SIP VoIP phone systems
with PoE. All 1600-IP Series phones meet ADA requirements for elevator or
emergency telephones, and can be programmed from any touch tone phone or
PC on the same LAN or remotely using a static IP address. The phones can dial
up to 5 programmable emergency numbers. In addition, the E-1600-20-IP,
E-1600-22-IP, E-1600-52-IP and E-1600-TP2IPEWP feature a second "INFO"
button that will dial up to 5 non-emergency numbers. Two amp relay contacts are
provided for strobe light, camera, door/gate control, etc.
The 1600-IP Series phones can be programmed to automatically deliver a digital
announcement to identify the location of the emergency call. Alternatively, a DTMF
touch tone code may also be delivered. A “Call Connected” LED can be initiated
manually or automatically. All programming parameters, including phone numbers
and location numbers, are stored in non-volatile memory, requiring no batteries.
All units are PoE powered.
For outdoor installations where the unit is exposed to precipitation or condensation,
select 1600-IP Series phones are available with Enhanced Weather Protection
(EWP). EWP products are designed to meet IP66 standards and may feature foam
rubber gaskets, sealed connections, gel-filled butt connectors, as well as potted
circuit boards with internally sealed, field-adjustable trim pots and DIP switches for
easy onsite programming. For more information on EWP, see DOD 859.
PRODUCT
MANUAL
Designed, Manufactured and Supported in the USA
1600-IP Series
ADA Compliant VoIP
Emergency Phones
October 2, 2023
SECURITY & COMMUNICATION
VIKING
E-1600-45-IPE-1600-IP
E-1600-03-IP
E-1600-20-IP E-1600-55-IP
E-1600-30-IP
E-1600-65-IP E-1600-60-IP
E-1600-32-IP
E-1600-SS-IP E-1600-RD-IP E-1600-YL-IP E-1600-BL-IP E-1600-BLP-IP E-1600-BK-IP
E-1600-02-IP/E-1600-TP-IPEWP
E-1600-TP2IPEWP/E-1600-GT-IPEWP
E-1600-50/52-IP
E-1600-53-IP
Installation requires a Network Administrator / IT Technician
!
