The World’s best kits.

®



MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 12/8/22 INST108-FD5CH

INSTALLATION INSTRUCTIONS

108-FD5CH

Patent # 10,579,232

Attention!With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

KIT FEATURES

• Designed specifically for the Pioneer DMH-C5500NEX 8-inch radio

• Included interface for climate and steering wheel functions

• Integrated passenger airbag indicator

• Touchscreen display for climate and personalization features

• Painted charcoal

KIT COMPONENTS

• A) Radio trim panel (with touchscreen display) • B) Radio brackets • C) Engine start/stop circuit board and cover

• D) Engine start/stop trim

• E) (6) Phillips screws

• F) (4) Panel clips • G) USB cable • H) HVAC interface and wiring harness (not shown) • I) Antenna adapter (not shown)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 9/32” socket wrench • Cutting tool

• Torx T-10 screwdriver

TABLE OF CONTENTS

Dash Disassembly ..............................................2-4

Kit Preparation ....................................................5-7

Kit Assembly ..........................................................8

Axxess Interface installation ............................9-17

Final Assembly ......................................................13

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Axxess interface built

into touchscreen

Antenna Adapter: Included with kit

Ford Mustang (with 4.2” screen) 2015-Up

AB

E

CD

FG

Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle

specific applications
