CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-LCD

INSTALLATION INSTRUCTIONS

axxessinterface.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 5/29/18 INSTAX-LCD

INTERFACE FEATURES

INTERFACE COMPONENTS

APPLICATIONS

TOOLS REQUIRED

• Cutting tool • Crimping tool • Tape

• Connectors (example: butt-connectors,

bell caps, etc.)

TABLE OF CONTENTS

Connections to be made .......................................4

Using the LCD screen .........................................5-6

Axxess LCD screen2000-up*

• Retains the personalization menu that is lost when removing the factory radio

(select applications)

• Retains and controls the factory satellite radio while using an Axxess interface

(select applications)

• Adjustable 256 color LCD screen

• Wire channel for flexible mounting

• Micro “B” USB updatable

• LCD Screen

• DIN harness with leads

• See pages 2-3

*Visit axxessinterfaces.com for up-to-date vehicle specific applications.
