Installation Instructions for AXBUCH-CH1

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

REV. 1/20/20

axxessinterfaces.com • metraonline.com

Axxess Integrate

FEATURES

• Retains the factory back-up camera to an aftermarket radio.

INTERFACE COMPONENTS

• AXBUCH-CH1 harness

AXBUCH-CH1

Chrysler Backup Camera Retention

2011-2016

CHRYSLER

300 2011-2014

DODGE

Charger 2011-2014

Dart 2014*

Journey 2011-2016

APPLICATIONS

* With premium amp, at the tuner brain behind the glove box.

TOOLS REQUIED

• Cutting Tool • Tape • Crimping Tool

• Connectors (example: butt connectors, bell caps, etc.)

Connections to be made

• Connect the wire to chassis ground. Black

• Connect the femaleYellow RCA jack to the aftermarket radios backup camera input.

CAUTION!

All accessories, switches, climate controls panels, and especially air bag indicator lights

must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.
