AXDIS-FD1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 11/4/19 INSTAXDIS-FD1

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape • Connectors (example: butt-connectors, bell caps, etc.) • Small flat-blade screwdriver

TABLE OF CONTENTS

Connections ........................................................3-5

- For models without a Sony/THX amplifier........4

- For models with a Sony/THX amplifier .............4

- 3.5mm jack steering wheel control retention ..5

Installation .............................................................5

Programming .........................................................6

Adjustments ...........................................................6

Extra features .........................................................7

Steering wheel control settings ......................7-10

- L.E.D. feedback ....................................................7

- Changing radio type ...........................................8

- Remapping ..........................................................8

- Dual assignment instructions .......................9-10

Troubleshooting ...................................................10

Ford Data Interface with SWC2007-Up

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, speed sense)

•

Retains audio controls on the steering wheel

• Retains RSE (rear seat entertainment)

• Retains SAT (satellite radio)

• Retains SYNC

• Retains the factory AUX-IN jack

• Can be used in both non-amplified and amplified models

(including Sony/THX)

• Retains balance and fade (excluding Sony/THX)

• Micro-B USB updatable

• AXDIS-FD1 interface

• AXDIS-FD1 harness

• 16-pin harness with stripped leads

• Female 3.5mm connector with stripped leads

APPLICATIONS

See inside front cover
