AXRSEH-G2

INSTALLATION INSTRUCTIONS

REV. 4/20/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.com

• Retains the A/V-IN jack (if applicable)

• Provides A/V output to the factory installed rear seat overhead

entertainment system *

• Designed for models that have a DVD player built into the factory radio

INTERFACE FEATURES

• Wire cutter • Crimping tool

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

GM

(with NAV)

RSE A/V Harness 2012-2014

APPLICATIONS

• AXRSEH-G2 harness

• Connect to the AXRSEH-G2 harness to the wiring harness in the

vehicle located at the radio location.

INTERFACE COMPONENTS

CONNECTIONS TO BE MADE

INSTALLATION

* Only applicable for models with a second row RSE

•

Connect the wire with a ring terminal to the chassis of the aftermarket radioBlack

.

• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the

aftermarket radio:

• Connect the Yellow RCA jack to the video in.

• Connect the and RCA jacks to the audio in.RedWhite

• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the

aftermarket radio:

• Connect the Yellow RCA jack to the video out.

• Connect the and RCA jacks to the audio out.RedWhite

CADILLAC

Escalade 2012-2014

CHEVROLET

Avalanche 2012-2013

Silverado 2500/3500 2014

Silverado 2012-2013

CHEVROLET (CONT)

Suburban 2012-2014

Tahoe 2012-2014

GMC

Sierra 2500/3500 2014

Sierra 2012-2013

Yukon 2012-2014
