METRA. The World’s best kits.™metraonline.com1-800-221-0932

© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION

Installation Instructions for LC-GMRC-LAN-09

REV. 12/16/2013 INSTLC-GMRC-LAN-09

(continued on back)

LC-GMRC-LAN-09

Silverado/Sierra 1500 chime retention

interface 2014-up

CONNECTIONS TO BE MADE

From the 4-pin harness

•ConnecttheRedwiretotheradiosaccessorywire.

•Connectthe4-pinharnessintotheLC-GMRC-LAN-09.

From the 16 and 20-pin harness

•Connectthe Yellowwiretotheradiosconstant/memorywire.

•ConnecttheBlack wiretotheradiosgroundwire.

•ConnecttheWhitewiretotheradiosleftfront(+)speakerwire.

•ConnecttheWhite/Blackwiretotheradiosleftfront(-)speakerwire.

•ConnecttheGray wiretotheradiosrightfront(+)speakerwire.

•ConnecttheGray/Blackwiretotheradiosrightfront(-)speakerwire.

•ConnecttheGreenwiretotheradiosleftrear(+)speakerwire.

•ConnecttheGreen/Blackwiretotheradiosleftrear(-)speakerwire.

•ConnectthePurplewiretotheradiosrightrear(+)speakerwire.

•ConnectthePurple/Blackwiretotheradiosrightrear(-)speakerwire.

ToretaintheOE3.5mmjack(radiomusthaveanAudioAUXin).

•ConnecttheWhiteRCAtotheaftermarketradio’sleftAudioAUXin.

•ConnecttheRedRCAtotheaftermarketradio’srightAudioAUXin.

Caution: Metra recommends disconnecting the negative battery terminal before

beginning any installation. All accessories, switches, and especially air bag indicator

lights must be plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

INTERFACE COMPONENTS

•LC-GMRC-LAN-09interface

•4pinto16and20pinGMharnesswithstrippedleads

TOOLS REQUIRED

•Cuttingtool•Tape•Crimpingtool

•Connectors(i.e.butt-connectors,bellcaps,etc.)

CHEVROLET

Silverado15002014-up

GMC

Sierra15002014-up

APPLICATIONS

KIT FEATURES

•Providesaccessory(12volt3amp)

•RetainsR.A.P.(retainedaccessorypower)

•Usedinnon-amplifiedsystemsorwhenbypassinganamplifiedsystem

•RetainsOEAUXinput

•Highlevelspeakerinput

•Retainsfadeandbalance

•Retainsallwarningchimes

•USBupdatable
