Installation Instructions for GMRC-05

REV. 11/14/2013 INSTGMRC-05

(continued on next page)

GMRC-05

GM Class II data bus interface

1996-2002

• Provides accessory (12-volt 10-amp)

• Retains R.A.P. (Retained Accessory Power), if equipped

• Used in non-amplified systems or when replacing amplified systems

• Retains all warning chimes through onboard speaker

KIT FEATURES

• GMRC-05 data interface

• 10-pin to 24-pin GM harness with stripped leads

INTERFACE COMPONENTS

• Cutting tool • Crimping tool • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

CHEVROLET

Equinox 2005-2006

PONTIAC

Torrent 2006

APPLICATIONS

CONNECTIONS TO BE MADE

From the 10-pin harness:

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Plug the 10-pin harness into the GMRC-05.

From the 24-pin harness:

• Connect the Yellow wire to the radio's 12-volt battery or memory wire.

• Connect the Black wire to the radio's ground wire.

• Connect the Orange/White wire to the illumination wire of the aftermarket

radio. If the aftermarket radio has no illumination wire just tape off the

Orange/White wire.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

• Connect the Gray/Black wire to the right front negative speaker output of the

aftermarket radio.

• Connect the Green wire to the radio’s left rear positive speaker output.

• Connect the Green/Black wire to the radio’s left rear negative speaker output.
