INSTALLATION INSTRUCTIONS FOR PART ASWC-TOY-LEX
METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2013 METRA ELECTRONICS CORPORATION
REV. 1/2/2014 INSTASWC-TOY-LEX
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• OneInterfacedoesitall-Noadditionalinterfacesneeded
• Automaticallyprogramsthebuttonsonthesteeringwheel
• Autodetectswhatradioit’sconnectedto
• Workswithallmajorradiobrands
• USBupdatable
• Allconnectionsaremadebehindtheradio
• Non-volatilememoryretainssettingsevenifbatteryisdisconnectedorinterfaceis
removedfromthevehicle
KIT FEATURES
•Cuttingtool•Crimpingtool•Tape•Connectors
(example:butt-connectors,bellcaps,etc.)
TOOLS REQUIRED
Axxess Steering Wheel Control interface
for select Toyota and Lexus vehicles
APPLICATIONS
See inside front cover
•ASWC-TOY-LEXinterface•12-pinharnesswith
male3.5mmto12and6-pinharness•Female
3.5mmconnectorwithBrownandBrown/White
wires•12kohmresistor
INTERFACE COMPONENTS
ASWC-TOY-LEX
Applications
TOYOTA
Avalon 2003-2004
Prius 2001-2003
Sienna 1999-2003
LEXUS
GS300 1998-2005
GS430 2001-2005
LX470 2001-2002
SC430 2002-2009
Into vehicle
1) Connectthe wireoftheASWC-TOY-LEXtoground. mayusethesameBlack You
groundingpointastheaftermarketradio.
2) Connectthe wireoftheASWC-TOY-LEXtoa12voltaccessorywire,onethatturnsRed
onandoffwiththeignitionkey.
3) Dependingonthevehicleyouareinconnecteitherthe6-pinor12-pinconnectortothe
matingvehicleharness.
To radio
1) theradiosbelow,plugtheincludedfemale3.5mmconnectorwiththe and For Brown
Brown/Whitewiresintothemale3.5mmconnectoroftheASWC-TOY-LEXharness.
• ConnecttheEclipsesteeringwheelcontrolwires(normallyFor Eclipse radios:
Brown Brown/Black Brown Brown/White and )tothe and wiresofthe
ASWC-TOY-LEX.BrownoftheASWC-TOY-LEXgoestothe oftheBrown/Black
Eclipseand oftheASWC-TOY-LEXgoestothe oftheEclipse.Brown/White Brown
• ConnecttheSWCKey1wire tothe wireoftheFor Metra OE: (Grey) Brown
ASWC-TOY-LEX.Isolateandtapethe wire,itwillnotbeused.Brown/White
• For Kenwood or select JVC’s Blue/Yellowwitha steeringwheelcontrolwire:
ConnecttheKenwood/JVCsteeringwheelcontrolwiretothe wireoftheBrown
ASWC-TOY-LEX.Isolateandtapethe wire,itwillnotbeused.Brown/White
Installation
Table of Contents
Installation
– Intovehicle............................................................................................2
– Toradio.............................................................................................. 2-3
Programming...........................................................................................3
Troubleshooting.......................................................................................3
Manually changing radio.........................................................................4
– Radiolegend..........................................................................................4
Remapping the SWC buttons..................................................................5
– Buttonassignmentlegend......................................................................5
– ResettingtheSWCbuttonsbacktodefault.............................................5
ASWC-TOY-LEX
Installation
Note: Some of the newer Kenwood radios will auto detect as a JVC. If this is
the case, use the included 12k ohm resistor in line between the Blue/Yellow
and Brown wire of the female 3.5mm jack during programming only (remove
resistor once programmed). Or you can manually set the radio type which is in
the Manually Changing Radio Type section.
2) For Parrot Asteroid Smart or Tablet:ConnecttheASWC-TOY-LEXmale3.5mm
jackintotheAX-SWC-PARROT(soldseparately)female3.5mmjackandplug
the4-pinendintothecorrespondingSWCplugontheradio.
 Note: AX-SWC-PARROT (sold separately) and radio required must be
updated to rev 2.1.4 or higher.
3) Pluginthemale3.5mmconnectoroftheASWC-TOY-LEXFor all other radios:
intothebackoftheaftermarketradio,designatedforanexternalsteeringwheel
controlinterface.Pleaserefertotheaftermarketradiosmanualifyouarein
doubtwherethe3.5mmconnectoroftheASWC-TOY-LEXgoes.
4) Onceallconnectionshavebeenmade,plugintheaftermarketradioifnot
donealready.
2) Oncesolid,theASWC-TOY-LEXshouldbeworking.
Note: The ASWC-TOY-LEX will give you two sets of LED feedback reports. The
first set of flashing green LED lights is for knowing the vehicle type and the
second set of red flashing LED lights is for knowing the radio type. Knowing the
vehicle type is irrelevant as this interface is pre-programmed for vehicles in the
application list only. But knowing the radio type is important for troubleshooting
if the ASWC-TOY-LEX does not work. Please see the below Radio Legend for
LED feedback information for radio type.
Programming
Troubleshooting
1) Confirmthatthe3.5mmconnectorisconnectedtoyourradiosecurely inand
thecorrectlocation.
2) Ifusingthefemale3.5mmconnectorinEclipse,Kenwood,selectJVC,orMetra
OEradios,verifythattheradio’ssteeringwheelcontrolwireisconnectedtothe
correctwiretotheASWC-TOY-LEX.
Note: Not every radio will have all the possible SWC commands on the steering
wheel. Please refer to the radio owner’s manual or contact the radio vendor for
specific commands that the radio will recognize.
TheASWC-TOY-LEXwillautoprogramitselfthroughAutoDetectMode.
1) TurntheignitiononandwaituntiltheLEDontheASWC-TOY-LEXgoessolid
(abouttwentyseconds).
Note:Do not press any buttons on the steering wheel or radio during this time.
Programming
