40VM900007 ERV
VRF (Variable Refrigerant Flow) System
Indoor Unit Interface
Manufacturer reserves the right to discontinue, or change at any time, specifications
or designs without notice and without incurring obligations.
Catalog No. 17-40VM900007-01 Printed in U.S.A. Form 40VM-6SI
Pg 1 09-17 Replaces: New
Installation and Operating Instructions
Part Number 40VM900007
CONTENTS Page
CONTENTS ..........................................................................................1
SAFETY CONSIDERATIONS ..............................................................2
GENERAL ............................................................................................3
ACCESSORIES ................................................................................... 4
DIMENSIONS ...................................................................................... 5
SELECTING INSTALLATION POSITION ............................................6
RECOMMENDED CLEARANCES .......................................................7
INSTALLATION ....................................................................................8
WIRING DETAILS.................................................................................9
POWER WIRING.................................................................................10
COMMUNICATION WIRING...............................................................11
TEMPERATURE SENSOR DETAILS ................................................13
THIRD-PARTY CONTROLLERS .......................................................15
CONTROL SIGNAL OUTPUT ............................................................16
DIP SWITCH SETTINGS ....................................................................17
OPERATING INSTRUCTIONS ...........................................................19
SIGNAL INPUT AND OUTPUT ..........................................................21
TROUBLESHOOTING .......................................................................24
Pg 2
SAFETY CONSIDERATIONS
Read and follow manufacturer instructions carefully. Follow all local
electrical codes during installation. All wiring must conform to local and national
electrical codes. Improper wiring or installation may damage thermostat.
Understand the signal words — DANGER, WARNING, and CAUTION.
DANGER identifies the most serious hazards, which will result in severe personal
injury or death. WARNING signifies hazards that could result in personal injury
or death. CAUTION is used to identify unsafe practices, which would result in
minor personal injury or product and property damage.
Recognize safety information. This is the safety-alert symbol ( ). When
this symbol is displayed on the unit and in instructions or manuals, be alert to the
potential for personal injury. Installing, starting up, and servicing equipment can
be hazardous due to system pressure, electrical components, and equipment
location.
“Note that changes or modifications of this product are not expressly
approved by the party responsible for compliance and could void the user’s
authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. these limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
P g 3
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
GENERAL
The ERV interface for the VRF (Variable Refrigerant Flow) system is a control
board that allows field-supplied ERV unit to tie into our VRF system.
