DIGITUS Industrial Gigabit Media
Converter RJ45
Manual
DN-652101-1&DN-652102-1
DN-652103-1&DN-652104-1

2
Table content of
1. Introducon ................................................................... 2
2. Features ......................................................................... 3
3. Package Contents 3 ..........................................................
4. Specicaons ................................................................. 3
5. Switch Panel 5 ..................................................................
6. Interface Denion 7 .......................................................
6.1 10/100/1000Base-TX ethernet interface ................. 7
6.2 1000base-FX ethernet interface .............................. 8
7. LED Indicator . 9 ................................................................
8. Installaon cauon ........................................................ 9
8.1 Installaon precauons ........................................... 9
8.2 Din rail installaon ................................................. 10
8.3 grounding .............................................................. 10
8.4 Power Connecon ................................................. 11
1. Introducon
This series of industrial media converter with 1-port
10/100/1000Mbps RJ45 +1 port 1000Mbps Optical meets CE
and RoHS standards. With operang temperature of - 40℃~
80 ℃, the switches can be adapted to all kinds of harsh
environment and also placed in the compact space of the
control box. The installaon characteriscs of the guide rail,
wide temperature operaon, IP40 protecon class housing
and LED indicator light make the media convertor a plug and
play industrial grade device, providing a reliable and
convenient soluon for users to network their Ethernet
devices.

3
2. Features
1. The use of high quality photoelectric integraon module
to provide good opcal and electrical characteriscs
2. Ensure reliable data transmission and long working life
3. Support full duplex or half duplex mode, with automac
negoaon capability
4. Network port support automac cross idencaon
5. Internal storage and forwarding mechanism, support a
variety of protocols
6. In line with industrial operating standards, the average
trouble-free work in more than 300,000 hours
7. Working power supply:
DC 12- V to provide reverse protecon 48
DC 48-57V for PoE version DN- - -1 DN 652104
3. Package Contents
Industrial switch 1pcs
User manual 1pcs
4. Specicaons
Standard
IEEE802.3i 10Base- T;
IEEE802.3u; 100Base-TX/FX;
IEEE802.3ab1000Base-T;
IEEE802.3z1000Base-X;
IEEE802.3x IEEE802.3af,
IEEE802.3at (DN- - 652104 1)
Interface
1-Port 10/100/1000Mbps RJ45
1 Port 0Mbps Opcal SC or SFP slot 100
