OMNITRONIC CST-508 2-Way Ceiling Speaker

Frameless 2-way coaxial speaker, LF: 5" HF: 0.75", 8 ohms, 30 W RMS

Art. No.: 80710214

GTIN: 4026397709094

List price: 95.08 €

incl. 19% VAT.

Logistic

EAN / GTIN: 4026397709094

Weight: 1,66 kg

Length: 0.24 m

Width: 0.24 m

Heigth: 0.15 m

Description:

The models of the CST series are frameless in-ceiling speakers with a particularly discreet

appearance for installation in hotels, restaurants, bars, foyers, training and conference rooms or

shopping centers. The 2-way coaxial systems have a frequency response of up to 20 kHz,

balanced sound and excellent speech intelligibility. The tweeter is protected against overload by

a PTC and can be tilted 30 degrees to adapt to local conditions, as well as freely rotated by

360°. Secure mounting clamps allow for fast and easy attachment. The front grille is

exchangeable.

Features:

- Excellent sound playback

- With passive 2-way crossover, PTC tweeter protection

- Swivel tweeter

- Level matching switch -3 dB/0 dB/+3 dB

- For speech and background music in indoor PA systems

- Scratchproof and shockproof

Package contents

- 1 x speaker, 1 x user manual

Technical specications:

Power: Program: 60W

Rated: 30W RMS

Frequency range: 50 - 20000 Hz

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

Sensitivity: 86 dB (1W/1m)

Max. SPL: 104 dB

Dispersion angle: 165° Omnidirectional

Impedance: 8 ohms

Speaker: 1 x woofer (5.3") approx. 13.5 cm

Tweeter (0.75") approx. 1.91 cm

Type of speaker: Flush-mount speaker

Material: ABS Acrylonitrile butadiene styrene

Color: White, scratchproof and shockproof

Mounting dimensions: 9,5 cm Ø 17,2 cm

Dimensions: Height: 9,6 cm

Diameter: Ø 21,1 cm

Weight: 1,24 kg
