OMNITRONIC ODX-215TM Installation Speaker 100V dark gray

Weather-proof 15" wall speaker with top-quality sound, incl. mount, 400 W RMS

Art. No.: 11036967

GTIN: 4026397703221

List price: 1010.31 €

incl. 19% VAT.

Logistic

EAN / GTIN: 4026397703221

Weight: 29,90 kg

Length: 0.61 m

Width: 0.59 m

Heigth: 0.57 m

Bulky product

Features:

- Well-balanced sound

- 2-way coaxial system with 38 cm woofer (15") and 4 cm tweeter (1.7")

- Power selector switch with 8 ohms operating position

- Screw terminals for parallel connection

- With Mounting bracket

- Suitable for outdoor use IP56

Package contents

- 1 x top, 1 x mounting bracket, 1 x user manual, 6 x screw, 1 x safety eyelet, 1 x lid, 8 x washer

Technical specications:

IP classication: IP56

Power: Program: 800W

Rated: 400W RMS

Frequency range: 50 - 18000 Hz

Sensitivity: 103 dB (1W/1m)

Max. SPL: 129 dB

Dispersion angle: 70° x 70°

Impedance: 8 ohms; Public address systems 100V

Attachment system: Mounting bracket

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

Power tapping: 75W; 150W; 300W; 400W RMS via Selector

switch switchable

Connections: Input: speaker via screw terminal

Crossover frequency: 2100 Hz

Speaker: 1 x woofer (15") approx. 38 cm

Voice coil lows (3") approx. 8 cm

1 x compression tweeter highs (1") approx. 2.5

Voice coil compression tweeter highs (1.7")

approx. 4.3 cm

Type of speaker: On-ceiling/on-wall speaker

Color: Grey

Dimensions: Width: 50 cm

Depth: 52 cm

Height: 50 cm

Weight: 26,80 kg
